GAM5-SF-1P-EN 6
Note: Heating and cooling speeds are the same, factory
set at Speed Tap #4.
Note: A “G” only signal from the comfort control will run
the blower at a lower speed, factory set at Speed Tap #1.
See the Sequence of Operation for additional information.
Note: Speed Tap 1 is NOT used for two stage systems.
Two stage systems will require an airflow adjustment.
AIRFLOW PERFORMANCE
GAM5B0B36M31SB, GAM5B0B36M31EA
EXTERNAL STATIC
(in w.g)
AIRFLOW (CFM)
Speed Taps - 230 VOLTS Speed Taps - 208 VOLTS
5 4 † 3 2 1 5 4 † 3 2 1
0 1438 1387 1197 1013 732 1435 1383 1194 1009 729
0.1 1394 1340 1143 945 552 1388 1334 1137 939 546
0.2 1350 1299 1090 892 413 1341 1291 1082 884 404
0.3 1301 1245 1031 817 305 1289 1233 1019 806 293
0.4 1253 1197 975 751 209 1239 1183 960 737 195
0.5 1205 1151 917 651 - 1188 1134 900 634 -
0.6 1155 1094 837 578 - 1136 1075 817 559 -
0.7 1099 1032 766 499 - 1077 1010 744 476 -
0.8 1039 972 691 453 - 1014 946 666 - -
0.9 964 889 633 409 - 936 861 605 - -
NOTES:
1. Values are with wet coil and without filters.
2. Contact your particular filter manufacturer for pressure drop data.
3. Electric heater pressure drop is negligible and is included within the airflow data.
4. Tap 1 is an continuous fan speed tap for single stage systems. Airflow adjustment is required for 2 stage systems.
See Airflow adjustment section.
5. † Factory Setting
GAM5B0B36M31SB, GAM5B0B36M31EA MINIMUM HEATER AIRFLOW CFM
Heater Minimum Air Speed Tap
Without HP With HP
BAYEAAC04BK1
BAYEAAC04LG1
Tap 2 Tap 3
BAYEAAC05BK1
BAYEAAC05LG1
Tap 2 Tap 3
BAYEAAC08BK1
BAYEAAC08LG1
Tap 3 Tap 4
BAYEAAC10BK1
BAYEAAC10LG1
Tap 4 Tap 5
BAYEAAC10LG3 Tap 4 Tap 5
BAYEABC15BK1 Tap 4 Tap 5
BAYEABC15LG3 Tap 4 Tap 5
BAYEABC20BK1 - -
BAYEACC25BK1 - -
