Setting Rotary Dial Address Using Embedded BCI2
Software Tool
Previous versions of BCI-C had rotary dials to set the controller
address. The BCI2-C controller does not have rotary dials to
set the address. A default address is set at the factory and
recorded on a label applied to the circuit board. The address
can be changed using the embedded BCI2 Service Tool.
Follow these instructions to change the address of the
controller:
1. Use a USB-A to USB-B cable. Plug the USB-B end into the
Service Port on the BCI2. Plug the USB-A end into a
laptop.
2. Open a browser in the laptop.
3. Enter 198.80.18.1
4. The BCI2 Service Tool will be served up from the BCI2
controller.
5. Navigate to Installation > Identification and
Communication > Protocol Configuration > Edit.
6. Set the Rotary Dial Setting (address) by clicking the line
and typing in the new address.
7. If the Device ID needs to be changed, check the box next
to Use Software Device ID and enter the desired device ID.
Note: All devices are MSTP managers with valid MAC
addresses of 001 to 127 for BACnet.
Figure 7. Setting rotary dial address
