8 RF-SVN006C-EN
Installing BCI2-C in the Chiller Control Panel
Before installing the BCI2-C kit, open the box and verify that
the following parts are enclosed:
Important: Visually inspect contents for obvious defects or
damage. All components have been
thoroughly inspected before leaving the
factory. Any claims for damage incurred during
shipment should be filed immediately with the
carrier.
Installation
Important: Before beginning installation, it is important to
read the following safety warnings. Procedures
presented in this guide should be performed
only by qualified HVAC technicians.
Note: All mounting holes for brackets and DIN rail have been
pre-drilled.
To install the BCI2-C:
1. Disconnect all power from the chiller.
2. Open the control panel and mount the brackets
(573178900001) to the control panel using two (2),
#6-32 x 0.375 Phillips pan head, thread forming screws
(X25330033100). Use the mounting locations for the
specific chiller type as shown in the following illustrations:
Parts List
X13651793001 Module; BCI2-C
X19060374040 Wire Harness, 4 COND, 20 AWG
573178900001 Bracket; BCI2-C Module Mounting
23092075 CGAM - W Frame Units - Schematic
23115511 CGAM - V Frame Units - Schematic
23115510 CGAM Slant Frame Units - Schematic
23092097 RTAC - 2 Compressor Units Schematic
23094621 RTAC - 3 Compressor Units, X-Line Schematic
23094622 RTAC - 3 Compressor, Units Y-Delta Schematic
23094623 RTAC - 4 Compressor Units X-Line Schematic
23094624 RTAC - 4 Compressor Y-Delta Schematic
23097584
RTWD/RTUD 60-250 TON WATER COOLED CHILLER
Schematic
23097585
RTWD/RTUD 60-250 TON WATER COOLED CHILLER
Schematic
One (1) copy of service literature shipped with each unit (located in the control
panel)
Field Provided Parts
X25330033100
Screw; Phillips Panhead 0.375 inch, Thread Rolling Zinc
Plate # 6-32
X25020783130
Screw; TORX Panhead 0.75 inch, Thread Rolling Zinc Plate
# 6-32
WARNING
Live Electrical Components!
Failure to follow all electrical safety precautions when
exposed to live electrical components could result in
death or serious injury.
When necessary to work with live electrical
components, have a qualified licensed electrician or
other individual who has been properly trained in
handling live electrical components perform these
tasks.
WARNING
Hazardous Voltage!
Failure to disconnect power before servicing could
result in death or serious injury.
Disconnect all electric power, including remote
disconnects before servicing. Follow proper lockout/
tagout procedures to ensure the power can not be
inadvertently energized. Verify that no power is present
with a voltmeter.
