Trane BCI-I - Analog Value Data

ACC-SVP01B-EN • BCI-I Integration Guide 27
Object Data Points and Diagnostic Data Points
Analog Input, 64
Energy Recovery Exhaust Air Bypass Damper
Position
Energy recovery exhaust air bypass damper position. Percent (98)
Analog Input, 65
Energy Recovery Leaving Exhaust Air
Tem perat ur e
Energy recovery leaving exhaust air temperature. Degrees-Fahrenheit (64)
Analog Input, 66
Energy Recovery Outdoor Air Bypass Damper
Position
Energy recovery outdoor air bypass damper position. Percent (98)
Analog Input, 67
Daytime Warmup Initiate Temperature
Setpoint Local
The local daytime warmup initiate temperature
setpoint.
Degrees-Fahrenheit (64)
Analog Input, 68
Daytime Warmup Terminate Temperature
Setpoint
Temperature setpoint that will exit daytime warmup
mode.
Degrees-Fahrenheit (64)
Analog Input, 69 Economizing Temperature Enable Setpoint
Temperature setpoint below which economizing can be
used.
Degrees-Fahrenheit (64)
Analog Input, 70 Economizing Enthalpy Enable Setpoint
Enthalpy setpoint below which economizing can be
used.
BTUs-per-pound (117)
Analog Input, 71 Exhaust Enable Damper Position Setpoint
Exhaust air damper minimum position to enable
exhaust sequence.
Percent (98)
Analog Input, 74 Space Temperature Cooling Setpoint Input
Cooling temperature setpoint from space sensor
module.
Degrees-Fahrenheit (64)
Analog Input, 75 Space Temperature Heating Setpoint Input
Heating temperature setpoint from space sensor
module.
Degrees-Fahrenheit (64)
Analog Input, 76 Humidification Capacity Status
Indicates the unit humidification capacity being
utilized.
Percent (98)
Analog Input, 78 Space Temperature Setpoint Local The local space temperature setpoint. Degrees-Fahrenheit (64)
Analog Input, 79 Dehumidification Capacity Status
Indicates the unit dehumidification capacity being
utilized.
Percent (98)
Analog Input, 80 Cabinet Style Describes the cabinet style of the unit. NA
Analog Input, 81 Cool Type Describes the cooling type installed in the unit. NA
Analog Input, 82 Preheat Type Describes the heating type installed in the unit. NA
Analog Input, 83 Reheat Type Describes the reheat type installed in the unit. NA
Analog Input, 84 Space CO2 High Limit Setpoint
Indicates the high limit space CO
2
setpoint for
ventilation.
Parts-per-million (96)
Analog Input, 85 Space CO2 Low Limit Setpoint
Indicates the low limit space CO
2
setpoint for
ventilation.
Parts-per-million (96)
Analog Input, 86 Economizer Minimum Position Setpoint Local
Indicates the local economizer minimum position
setpoint.
Percent (98)
Analog Input, 87 Space Air Temperature Local
The space air temperature measured by a unit-
mounted sensor.
Degrees-Fahrenheit (64)
Analog Input, 88 Unit Energy Demand
Indicates the current heat/cool energy demand of the
unit.
Percent (98)
Analog Input, 89 Supply Fan Type Describes the supply fan type installed in the unit. NA
Analog Input, 90 Exhaust or Return Fan Type
Describes the exhaust or return fan type installed in the
unit.
NA
Table 5. Analog Value
Object Identifier Object Name Description Units Valid Range
Analog Value, 1 Filter Runtime Hours Setpoint
The setpoint value
used by the filter
run hours
calculation.
Hours (71) 0 to 10,000
Table 4. Analog Input (continued)
Object Identifier Object Name Description
Units (Listed Are Defaults)
