Trane BCI-I - Multistate Output Data; Multistate Input Data

28 ACC-SVP01B-EN • BCI-I Integration Guide
Object Data Points and Diagnostic Data Points
Table 6. Multistate Output
BCI-I Object Identifier Object Name Description Object States
Multi-State Output, 1 Economizer Airside Enable BAS Command the state of the airside economizer system.
1 = Disabled
2 = Enabled
3 = Auto
Multi-State Output, 2 Emergency Override BAS Command the unit into an emergency mode of operation.
1 = Normal
2 = Pressurize
3 = Depressurize
4 = Purge
5 = Shutdown
6 = Fire
Multi-State Output, 3 Economizer Waterside Enable BAS Command the state of the waterside economizer system.
1 = Disabled
2 = Enabled
3 = Auto
Multi-State Output, 7 Occupancy Mode Request BAS Command the unit into an occupancy mode.
1 = Occupied
2= Unoccupied
3 = Occupied Bypass
4 = Occupied Standby
Multi-State Output, 8 Application Mode Request BAS Command the unit to a specific application mode.
1 = Auto
2 = Heat
3 = Morning Warmup
4 = Cool
5 = Night Purge
6 = Precool
7 = Off
8 = Test
9 = Emergency Heat
10 = Fan Only
11 = Free Cool
12 = Ice Making
13 = Max Heat
14 = Economy Mode
15 = Dehumidifying
16 = Calibrate
Multi-State Output, 10 Condenser Water Flow BAS
Command the unit to utilize a remote water flow
indication.
1 = Flow
2 = No Flow
3 = Auto
Table 7. Multistate Input
BCI-I Object
Identifier
Object Name Description Object States
Multi-State Input, 2 Trane Unit Type
General description of the equipment-type
classification.
1 = 1 Heat/1 Cool
2 = Heat Pump
3 = Blower Coil
4 = Unit Ventilator
5 = Fan Coil
6 = Rooftop
7 = Air Handler
8 = Vertical Self Contained
9 = Unitary
10 = VAV Box
11 = Fan Coil
Multi-State Input, 9 Economizer Type
General description of the equipment
economizer system.
1 = None
2 = 2 Position Ventilation
3 = Modulation Economizer
4 = 2 Position Ventilation/Waterside Economizer
5 = Waterside Economizer
6 = Airside/Waterside Economizer
7 = TRAQ Damper
8 = Airside Economizer and TRAQ Damper/Sensor
9 = Waterside Economizer and TRAQ Damper/Sensor
10 = Airside/Waterside Economizer and TRAQ Damper/Sensor
Multi-State Input, 10 Condenser Type
General description of the equipment
condenser system.
1 = None
2 = Air Cooled
3 = Water Cooled
4 = Evaporative
Multi-State Input, 13 Ventilation Override Status
Indicates if the unit is in a ventilation
override mode of operation.
1= Inactive
2= Mode A Active
3= Mode B Active
4= Mode C Active
5= Mode D Active
6= Mode E Active
