30 ACC-SVP01B-EN • BCI-I Integration Guide
Object Data Points and Diagnostic Data Points
Multi-State Input, 32 Heat Output 4
Indicates the commanded state of heating
output 4.
1 = Off
2 = On
3 = Not Present
Multi-State Input, 33 Heat Output 5
Indicates the commanded state of heating
output 5.
1 = Off
2 = On
3 = Not Present
Multi-State Input, 34 Prefilter Status Indicates the prefilter media state.
1 = Clean
2 = Dirty
3 = Not Present
Multi-State Input, 35 Primary Filter Status Indicates the primary filter media state.
1 = Clean
2 = Dirty
3 = Not Present
Multi-State Input, 36 Final Filter Status Indicates the final filter media state.
1 = Clean
2 = Dirty
3 = Not Present
Multi-State Input, 37 Supply Fan Proving Status Indicates the current state of the supply fan.
1= Off
2= On
3= Not Present
Multi-State Input, 38 Exhaust Fan Status
Indicates the commanded state of the
exhaust fan.
1 = Off
2 = On
3 = Not Present
Multi-State Input, 39
Exhaust Fan Proving
Status
Indicates if the unit exhaust fan is off or on.
1= Off
2= On
3= Not Present
Multi-State Input, 40 Return Fan Proving Status Indicates the current state of the return fan.
1= Off
2= On
3= Not Present
Multi-State Input, 41 Supply Fan Status Indicates the state of the supply fan.
1 = Off
2 = On
3 = Not Present
Multi-State Input, 42 Return Fan Status Indicates the state of the return fan.
1 = Off
2 = On
3 = Not Present
Multi-State Input, 43
Outdoor Air Damper
Status
Indicates the operating state of the outdoor
damper.
1 = At or Below Minimum Position
2 = Above Minimum Position
3 = Not Present
Multi-State Input, 44 Economizer System Status
Indicates the operating state of the
waterside economizer system.
1 = Disabled
2 = Enabled
3 = Not Present
Table 8. Binary Output
Object Identifier Object Name Description
Relinquish
Default
Object States
Binary Output, 1 System Control Command
Command the unit to standalone-
or BAS-controlled operation.
Inactive
Inactive = Standalone Control
Active = BAS Control
Binary Output, 5 Heat Lockout Command
Command the unit to prevent
heating operation.
Inactive
Inactive = Allow Heating
Active = Heating Locked Out
Binary Output, 6 Cool Lockout Command
Command the unit to prevent
cooling operation.
Inactive
Inactive = Allow Cooling
Active = Cooling Locked Out
Binary Output, 7 Economizer Minimum Position Command
Command the unit to the minimum
position operation.
Inactive
Inactive = Disabled
Active = Enabled
Binary Output, 8 Supply Fan Configuration Command
Command the unit supply fan to
cycling or continuous operation.
Inactive
Inactive = Auto
Active = On
Binary Output, 12 Heat or Reheat Enable Command
Enable the heating or reheating
system during dehumidification
mode.
Inactive
Inactive = Disabled
Active = Enabled
Binary Output, 13 Filter Timer Reset Command
Command the unit to reset the
accumulated filter run hours.
Inactive
Inactive = Accumulating
Active = Reset
Binary Output, 14 Diagnostic Reset Command
Command the unit to reset and
clear diagnostics.
Inactive
Inactive = Normal
Active = Reset
