34 ACC-SVP01B-EN • BCI-I Integration Guide
Object Data Points and Diagnostic Data Points
Binary Input, 124 Diagnostic: Unocc Dehumid Setpoint Fail Diagnostic: Unocc Dehumid Setpoint Fail
Binary Input, 125 Diagnostic: Occ Dehumid Setpoint Failure Diagnostic: Occ Dehumid Setpoint Failure
Binary Input, 126 Diagnostic: Unocc Humid Setpoint Fail Diagnostic: Unocc Humid Setpoint Fail
Binary Input, 127 Diagnostic: Occ Humid Setpoint Failure Diagnostic: Occ Humid Setpoint Failure
Binary Input, 128 Diagnostic: MDM Communications Failure Diagnostic: MDM Communications Failure
Binary Input, 129 Diagnostic: Dirty Final Filter Diagnostic: Dirty Final Filter
Binary Input, 130 Diagnostic: Vel Press Sensor (Front) Fail Diagnostic: Vel Press Sensor (Front) Fail
Binary Input, 131 Diagnostic: High Superheat - Ckt 1 Diagnostic: High Superheat - Ckt 1
Binary Input, 132 Diagnostic: Low Refrigerant Charge - Ckt 1 Diagnostic: Low Refrigerant Charge - Ckt 1
Binary Input, 133 Diagnostic: High Superheat - Ckt 2 Diagnostic: High Superheat - Ckt 2
Binary Input, 134 Diagnostic: Low Refrigerant Charge - Ckt 2 Diagnostic: Low Refrigerant Charge - Ckt 2
Binary Input, 139 Diagnostic: MPM Communications Failure Diagnostic: MPM Communications Failure
Binary Input, 140 Diagnostic: TPM Communications Failure Diagnostic: TPM Communications Failure
Binary Input, 141 Diagnostic: Return Plenum Press Sensor Diagnostic: Return Plenum Press Sensor
Binary Input, 142 Diagnostic: Return Press High Limit (Man) Diagnostic: Return Press High Limit (Man)
Binary Input, 143 Diagnostic: Return Press High Limit (Auto) Diagnostic: Return Press High Limit (Auto)
Binary Input, 144 Diagnostic: Cond Press Sensor Fail Ckt 2 Diagnostic: Cond Press Sensor Fail Ckt 2
Binary Input, 145 Diagnostic: Cond Press Sensor Fail Ckt 1 Diagnostic: Cond Press Sensor Fail Ckt 1
Binary Input, 146 Diagnostic: Invalid Unit Configuration Diagnostic: Invalid Unit Configuration
Binary Input, 147 Diagnostic: Maintenance Required Diagnostic: Maintenance Required
Binary Input, 148 Diagnostic: Unit Communications Failure Diagnostic: Unit Communications Failure
Binary Input, 149 Diagnostic: Unit Stopped at Local HI Diagnostic: Unit Stopped at Local HI
Binary Input, 150 Diagnostic: Unit Stopped at Remote HI Diagnostic: Unit Stopped at Remote HI
Binary Input, 151 Diagnostic: RTM External Stop Diagnostic: RTM External Stop
Binary Input, 166 Diagnostic: Stop Status Diagnostic: Stop Status
Binary Input, 233 Diagnostic: Sump Min Level Cycling (man) Diagnostic: Sump Min Level Cycling (man)
(a) Object States: Inactive = normal and Active = foreign language specific
Table 11. All Object Types Sorted by Object Name (Refer to previous tables for detailed descriptions of objects)
Object Identifier
(a)
Object Name Description
Binary Input, 165 Alarm Relay Output Status Indicates the state of the alarm relay on the unit.
Multi-State Output, 8 Application Mode Request BAS Command the unit to a specific application mode.
Multi-State Input, 19 Application Mode Status Indicates the current application mode of the equipment.
Analog Input, 80 Cabinet Style Describes the cabinet style of the unit.
Binary Input, 2 Compressor Lockout Status One or more compressors are locked out with no diagnostic.
Analog Input, 14 Condenser Capacity Status Indicates the unit condenser capacity being utilized.
Multi-State Input, 10 Condenser Type General description of the equipment condenser system.
Binary Input, 243 Condenser Water Drain Status Indicates the status of the condenser water drain
Analog Input, 35 Condenser Water Entering Temperature The temperature of the water entering the condenser.
Multi-State Output, 10 Condenser Water Flow BAS Command the unit to utilize a remote water flow indication.
Binary Input, 25 Condenser Water Flow Status Indicates the flow status of water in the condenser system.
Analog Input, 46 Condenser Water Leaving Temperature Active Condenser water leaving temperature value used for unit control.
Analog Input, 47 Condenser Water Leaving Temperature Local Condenser water leaving temperature from a unit-mounted sensor.
Binary Input, 24 Condenser Water Pump Status Indicates the status of the condenser water system pump.
Analog Input, 42 Condensing Saturated Temperature Circuit 1 Indicates the saturated condenser temperature for circuit 1.
Table 10. Diagnostics, Binary Input (continued)
Object Identifier
(a)
Object Name Description
