Object Data Points and Diagnostic Data Points
Analog Input, 43 Condensing Saturated Temperature Circuit 2 Indicates the saturated condenser temperature for circuit 2.
Analog Input, 44 Condensing Saturated Temperature Circuit 3 Indicates the saturated condenser temperature for circuit 3.
Analog Input, 45 Condensing Saturated Temperature Circuit 4 Indicates the saturated condenser temperature for circuit 4.
Analog Output, 19 Cool Capacity Enable Setpoint BAS BAS supplied cooling demand limit capacity setpoint value.
Binary Output, 6 Cool Lockout Command Command the unit to prevent cooling operation.
Multi-State Input, 25 Cool Output 1 Indicates the commanded state of cooling output 1.
Multi-State Input, 26 Cool Output 2 Indicates the commanded state of cooling output 2.
Multi-State Input, 27 Cool Output 3 Indicates the commanded state of cooling output 3.
Multi-State Input, 28 Cool Output 4 Indicates the commanded state of cooling output 4.
Analog Input, 81 Cool Type Describes the cooling type installed in the unit.
Analog Input, 1 Cooling Capacity Status Indicates the unit cooling capacity being utilized.
Multi-State Input, 17 Cooling Reset Type Status Indicates the type of cooling reset.
Multi-State Input, 22 Cooling Setpoint Source Indicates the source of the space cooling setpoint.
Analog Input, 55
Daytime Warmup Air Temperature Initiate Setpoint
Active
The air temperature setpoint used to start daytime warmup mode.
Analog Input, 67 Daytime Warmup Initiate Temperature Setpoint Local The local daytime warmup initiate temperature setpoint.
Analog Input, 68 Daytime Warmup Terminate Temperature Setpoint Temperature setpoint that will exit daytime warmup mode.
Analog Output, 5 Daytime Warmup Terminate Temperature Setpoint BAS BAS supplied daytime warmup terminate temperature setpoint.
Analog Input, 79 Dehumidification Capacity Status Indicates the unit dehumidification capacity being utilized.
Binary Output, 15 Dehumidification Command Command the operating state of the dehumidification system.
Analog Input, 58 Dehumidification High Limit Setpoint Humidity setpoint value that starts dehumidification control.
Binary Input, 10 Demand Limit Status Indicates if the unit is in an energy-demand limit mode
Binary Output, 14 Diagnostic Reset Command Command the unit to reset and clear diagnostics.
Binary Input, 166 Diagnostic Stop Status Indicates if the unit diagnostic has caused the unit to shutdown.
Analog Output, 6 Discharge Air Cooling Setpoint BAS BAS supplied discharge air temperature cooling setpoint value.
Analog Output, 22 Discharge Air Dewpoint Setpoint BAS BAS supplied discharge air dewpoint setpoint value.
Analog Input, 60 Discharge Air Dewpoint Temperature Setpoint Humidity setpoint value used during dehumidification control.
Analog Output, 7 Discharge Air Heating Setpoint BAS BAS supplied discharge air temperature heating setpoint value.
Analog Input, 61 Discharge Air Reheat Setpoint Active Indicates the active supply air reheat temperature setpoint.
Analog Output, 23 Discharge Air Reheat Setpoint BAS BAS supplied discharge air reheat setpoint value.
Analog Input, 24 Discharge Air Temperature Active The discharge air temperature currently used for unit control.
Analog Output, 12 Discharge Air Temperature BAS BAS supplied discharge air temperature sensor value.
Analog Input, 33 Discharge Air Temperature Dewpoint Discharge air temperature dewpoint being used by the unit.
Analog Input, 52 Discharge Air Temperature Setpoint Active Discharge air temperature setpoint value being used for unit control.
Analog Input, 28 Duct Static Air Pressure Active Duct static air pressure value currently being used for unit control.
Analog Output, 13 Duct Static Air Pressure BAS BAS supplied duct static air pressure sensor value.
Analog Input, 29 Duct Static Air Pressure Local Duct static air pressure value measured by a unit-mounted sensor.
Analog Input, 48 Duct Static Air Pressure Setpoint Active Duct static pressure setpoint value being used for unit control.
Analog Output, 8 Duct Static Air Pressure Setpoint BAS BAS supplied duct static air pressure setpoint value.
Multi-State Output, 1 Economizer Airside Enable BAS Command the state of the airside economizer system.
Multi-State Output, 1 Economizer Airside Enable BAS Command the state of the airside economizer system.
Binary Input, 22 Economizer Airside Enable Status Indicates the status of the airside economizer system.
Multi-State Input, 15 Economizer Decision Method Unit method to determine when the economizer system is enabled.
Binary Output, 7 Economizer Minimum Position Command Command the unit to economizer minimum position operation.
Analog Input, 56 Economizer Minimum Position Setpoint Active The minimum position value the economizer damper will utilize.
Analog Output, 1 Economizer Minimum Position Setpoint BAS BAS supplied economizer position minimum setpoint value.
Analog Input, 86 Economizer Minimum Position Setpoint Local Indicates the local economizer minimum position setpoint.
Table 11. All Object Types Sorted by Object Name (Refer to previous tables for detailed descriptions of objects) (continued)
Object Identifier
(a)
Object Name Description
