40 ACC-SVP01B-EN • BCI-I Integration Guide
Object Data Points and Diagnostic Data Points
BI 110 Diagnostic: Ent Evap Temp Sensor Fail-Ckt 4
0 = inactive
1 = active
Diagnostic: Ent Evap Temp Sensor Fail-Ckt 4
BI 96 Diagnostic: Enter Water Temp Sensor Fail
0 = inactive
1 = active
Diagnostic: Enter Water Temp Sensor Fail
BI 105 Diagnostic: Evap Temp Sensor Fail - Ckt3
0 = inactive
1 = active
Diagnostic: Evap Temp Sensor Fail - Ckt3
BI 104 Diagnostic: Evap Temp Sensor Fail - Ckt4
0 = inactive
1 = active
Diagnostic: Evap Temp Sensor Fail - Ckt4
BI 91 Diagnostic: Exh Fan VFD Bypass Enabled
0 = inactive
1 = active
Diagnostic: Exh Fan VFD Bypass Enabled
BI 40 Diagnostic: Exhaust/Return Fan Failure
0 = inactive
1 = active
Diagnostic: Exhaust/Return Fan Failure
BI 120 Diagnostic: GBAS 0-10 VDC Comm Failure
0 = inactive
1 = active
Diagnostic: GBAS 0-10 VDC Comm Failure
BI 65 Diagnostic: GBAS 0-5 VDC Comm Failure
0 = inactive
1 = active
Diagnostic: GBAS 0-5 VDC Comm Failure
BI 49 Diagnostic: HEAT Aux Temp Sensor Fail
0 = inactive
1 = active
Diagnostic: HEAT Aux Temp Sensor Fail
BI 63 Diagnostic: HEAT Communications Failure
0 = inactive
1 = active
Diagnostic: HEAT Communications Failure
BI 51 Diagnostic: Heat Failure
0 = inactive
1 = active
Diagnostic: Heat Failure
BI 99 Diagnostic: High CO2 Level
0 = inactive
1 = active
Diagnostic: High CO2 Level
BI 131 Diagnostic: High Superheat - Ckt 1
0 = inactive
1 = active
Diagnostic: High Superheat - Ckt 1
BI 133 Diagnostic: High Superheat - Ckt 2
0 = inactive
1 = active
Diagnostic: High Superheat - Ckt 2
BI 122 Diagnostic: Insufficient Airflow for Dehumid
0 = inactive
1 = active
Diagnostic: Insufficient Airflow for Dehumid
BI 146 Diagnostic: Invalid Unit Configuration
0 = inactive
1 = active
Diagnostic: Invalid Unit Configuration
BI 50 Diagnostic: Low Air Temp Limit Trip
0 = inactive
1 = active
Diagnostic: Low Air Temp Limit Trip
BI 43 Diagnostic: Low Pressure Ctl Open - Ckt1
0 = inactive
1 = active
Diagnostic: Low Pressure Ctl Open - Ckt1
BI 44 Diagnostic: Low Pressure Ctl Open - Ckt2
0 = inactive
1 = active
Diagnostic: Low Pressure Ctl Open - Ckt2
BI 101 Diagnostic: Low Pressure Ctl Open - Ckt3
0 = inactive
1 = active
Diagnostic: Low Pressure Ctl Open - Ckt3
BI 100 Diagnostic: Low Pressure Ctl Open - Ckt4
0 = inactive
1 = active
Diagnostic: Low Pressure Ctl Open - Ckt4
BI 132 Diagnostic: Low Refrigerant Charge - Ckt 1
0 = inactive
1 = active
Diagnostic: Low Refrigerant Charge - Ckt 1
BI 134 Diagnostic: Low Refrigerant Charge - Ckt 2
0 = inactive
1 = active
Diagnostic: Low Refrigerant Charge - Ckt 2
BI 41 Diagnostic: Lvg Evap Temp Sensor Fail - Ckt1
0 = inactive
1 = active
Diagnostic: Lvg Evap Temp Sensor Fail - Ckt1
BI 42 Diagnostic: Lvg Evap Temp Sensor Fail - Ckt2
0 = inactive
1 = active
Diagnostic: Lvg Evap Temp Sensor Fail - Ckt2
BI 147 Diagnostic: Maintenance Required
0 = inactive
1 = active
Diagnostic: Maintenance Required
BI 60 Diagnostic: Man - SA High Press Limit
0 = inactive
1 = active
Diagnostic: Man - SA High Press Limit
BI 62 Diagnostic: MCM Communications Failure
0 = inactive
1 = active
Diagnostic: MCM Communications Failure
BI 128 Diagnostic: MDM Communications Failure
0 = inactive
1 = active
Diagnostic: MDM Communications Failure
Table 12. Diagnostic Objects Sorted by Object Name (continued)
Object Identifier
(a)
Object Name Value/Range Description
