ACC-SVP01B-EN • BCI-I Integration Guide 41
Object Data Points and Diagnostic Data Points
BI 33 Diagnostic: Mode Input Failure
0 = inactive
1 = active
Diagnostic: Mode Input Failure
BI 139 Diagnostic: MPM Communications Failure
0 = inactive
1 = active
Diagnostic: MPM Communications Failure
BI 68 Diagnostic: NSB Panel Communication Fail
0 = inactive
1 = active
Diagnostic: NSB Panel Communication Fail
BI 77 Diagnostic: NSB Zone Temp Sensor Fail
0 = inactive
1 = active
Diagnostic: NSB Zone Temp Sensor Fail
BI 37 Diagnostic: OA Humidity Sensor Failure
0 = inactive
1 = active
Diagnostic: OA Humidity Sensor Failure
BI 32 Diagnostic: OA Temperature Sensor Fail
0 = inactive
1 = active
Diagnostic: OA Temperature Sensor Fail
BI 125 Diagnostic: Occ Dehumid Setpoint Failure
0 = inactive
1 = active
Diagnostic: Occ Dehumid Setpoint Failure
BI 127 Diagnostic: Occ Humid Setpoint Failure
0 = inactive
1 = active
Diagnostic: Occ Humid Setpoint Failure
BI 34 Diagnostic: Occ Zone Cool Setpoint Fail
0 = inactive
1 = active
Diagnostic: Occ Zone Cool Setpoint Fail
BI 35 Diagnostic: Occ Zone Heat Setpoint Fail
0 = inactive
1 = active
Diagnostic: Occ Zone Heat Setpoint Fail
BI 111 Diagnostic: Recovery Dirty Prefilter
0 = inactive
1 = active
Diagnostic: Recovery Dirty Prefilter
BI 112 Diagnostic: Recovery Lvg RA Sensor Fail
0 = inactive
1 = active
Diagnostic: Recovery Lvg RA Sensor Fail
BI 121 (use Object
Identifier for RT)
Diagnostic: Reheat Head Press High
0 = inactive
1 = active
Diagnostic: Reheat Head Press High
BI 119 Diagnostic: Reheat Sat Cond Temp Sensor
0 = inactive
1 = active
Diagnostic: Reheat Sat Cond Temp Sensor
BI 58 (use Object
Identifier for RT or CSC)
Diagnostic: Return Air RH Sensor Failure
0 = inactive
1 = active
Diagnostic: Return Air RH Sensor Failure
BI 57 Diagnostic: Return Air Temp Sensor Fail
0 = inactive
1 = active
Diagnostic: Return Air Temp Sensor Fail
BI 141 Diagnostic: Return Plenum Press Sensor
0 = inactive
1 = active
Diagnostic: Return Plenum Press Sensor
BI 143 Diagnostic: Return Press High Limit (Auto)
0 = inactive
1 = active
Diagnostic: Return Press High Limit (Auto)
BI 142 Diagnostic: Return Press High Limit (Man)
0 = inactive
1 = active
Diagnostic: Return Press High Limit (Man)
BI 31 (use Object
Identifier for RT CSC)
Diagnostic: RTM Aux Temp Sensor Failure
0 = inactive
1 = active
Diagnostic: RTM Aux Temp Sensor Failure
BI 69 Diagnostic: RTM EEPROM Failure
0 = inactive
1 = active
Diagnostic: RTM EEPROM Failure
BI 15 Diagnostic: RTM External Stop
0 = inactive
1 = active
Diagnostic: RTM External Stop
BI 151 Diagnostic: RTM External Stop
0 = inactive
1 = active
Diagnostic: RTM External Stop
BI 106 Diagnostic: RTM Zone Humidity Sensor Fail
0 = inactive
1 = active
Diagnostic: RTM Zone Humidity Sensor Fail
BI 29 Diagnostic: RTM Zone Temp Sensor Failure
0 = inactive
1 = active
Diagnostic: RTM Zone Temp Sensor Failure
BI 121 (use Object
Identifier for FAU)
Diagnostic: SA Drying Setpoint Failure
0 = inactive
1 = active
Diagnostic: SA Drying Setpoint Failure
B1 31 (use Object
Identifier for FAU)
Diagnostic: SA Drying Temp Sensor Fail
0 = inactive
1 = active
Diagnostic: SA Drying Temp Sensor Fail
BI 54 Diagnostic: SA Duct Press Setpoint Fail
0 = inactive
1 = active
Diagnostic: SA Duct Press Setpoint Fail
BI 123 Diagnostic: SA Reheat Setpoint Failure
0 = inactive
1 = active
Diagnostic: SA Reheat Setpoint Failure
Table 12. Diagnostic Objects Sorted by Object Name (continued)
Object Identifier
(a)
Object Name Value/Range Description
