42 ACC-SVP01B-EN • BCI-I Integration Guide
Object Data Points and Diagnostic Data Points
BI 74 Diagnostic: SA Temp Cool Setpoint Fail
0 = inactive
1 = active
Diagnostic: SA Temp Cool Setpoint Fail
BI 75 Diagnostic: SA Temp Heat Setpoint Fail
0 = inactive
1 = active
Diagnostic: SA Temp Heat Setpoint Fail
BI 61 Diagnostic: SCM Communications Failure
0 = inactive
1 = active
Diagnostic: SCM Communications Failure
BI 56 Diagnostic: Space Pressure Sensor Fail
0 = inactive
1 = active
Diagnostic: Space Pressure Sensor Fail
BI 55 Diagnostic: Space Pressure Setpoint Fail
0 = inactive
1 = active
Diagnostic: Space Pressure Setpoint Fail
BI 233 Diagnostic: Sump Min Level Cycling (man)
0 = inactive
1 = active
Diagnostic: Sump Min Level Cycling (man)
BI 36 Diagnostic: Supply Air Press Sensor Fail
0 = inactive
1 = active
Diagnostic: Supply Air Press Sensor Fail
BI 30 Diagnostic: Supply Air Temp Sensor Fail
0 = inactive
1 = active
Diagnostic: Supply Air Temp Sensor Fail
BI 39 Diagnostic: Supply Fan Failure
0 = inactive
1 = active
Diagnostic: Supply Fan Failure
BI 98 Diagnostic: Supply Fan VFD Bypass Enable
0 = inactive
1 = active
Diagnostic: Supply Fan VFD Bypass Enable
BI 140 Diagnostic: TPM Communications Failure
0 = inactive
1 = active
Diagnostic: TPM Communications Failure
BI 148 Diagnostic: Unit Communications Failure
0 = inactive
1 = active
Diagnostic: Unit Communications Failure
BI 70 Diagnostic: Unit HI Communications Fail
0 = inactive
1 = active
Diagnostic: Unit HI Communications Fail
BI 149 Diagnostic: Unit Stopped at Local HI
0 = inactive
1 = active
Diagnostic: Unit Stopped at Local HI
BI 150 Diagnostic: Unit Stopped at Remote HI
0 = inactive
1 = active
Diagnostic: Unit Stopped at Remote HI
BI 124 Diagnostic: Unocc Dehumid Setpoint Fail
0 = inactive
1 = active
Diagnostic: Unocc Dehumid Setpoint Fail
BI 126 Diagnostic: Unocc Humid Setpoint Fail
0 = inactive
1 = active
Diagnostic: Unocc Humid Setpoint Fail
BI 52 Diagnostic: Unocc Zone Cool Stpnt Fail
0 = inactive
1 = active
Diagnostic: Unocc Zone Cool Stpnt Fail
BI 53 Diagnostic: Unocc Zone Heat Stpnt Fail
0 = inactive
1 = active
Diagnostic: Unocc Zone Heat Stpnt Fail
BI 84 Diagnostic: VCM Aux Temp Sensor Failure
0 = inactive
1 = active
Diagnostic: VCM Aux Temp Sensor Failure
BI 87 Diagnostic: VCM Communications Failure
0 = inactive
1 = active
Diagnostic: VCM Communications Failure
BI 130 Diagnostic: Vel Press Sensor (Front) Fail
0 = inactive
1 = active
Diagnostic: Vel Press Sensor (Front) Fail
BI 86 (use Object
Identifier for Ipak II-RT)
Diagnostic: Vel Press Sensor (Rear)
0 = inactive
1 = active
Diagnostic: Vel Press Sensor (Rear)
BI 86
(use Object
Identifier for Ipak I-RT,
CSC, FAU)
Diagnostic: Velocity Press Sensor Fail
0 = inactive
1 = active
Diagnostic: Velocity Press Sensor Fail
BI 71 Diagnostic: VOM Communications Failure
0 = inactive
1 = active
Diagnostic: VOM Communications Failure
BI 78 Diagnostic: VOM Mode A Active
0 = inactive
1 = active
Diagnostic: VOM Mode A Active
BI 79 Diagnostic: VOM Mode B Active
0 = inactive
1 = active
Diagnostic: VOM Mode B Active
BI 80 Diagnostic: VOM Mode C Active
0 = inactive
1 = active
Diagnostic: VOM Mode C Active
BI 81 Diagnostic: VOM Mode D Active
0 = inactive
1 = active
Diagnostic: VOM Mode D Active
Table 12. Diagnostic Objects Sorted by Object Name (continued)
Object Identifier
(a)
Object Name Value/Range Description
