Installation
10 PART-SVN228B-EN
CGAM030 and CGAM035 Chillers
(S2, Slant Units)
Table 8. Kit contents FMF14493
# Qty Per Component Part Component Description
1 2 572095380100 SUPPORT; LOUVER
2 84 X25020604010 SCREW;M8 X 1.25MM X 16MM
3 8 572055590100 LOUVER; UNIT SIDE CGAM
4 1 572051000100 PANEL; BACK SIDE
5 1 572095690100 SUPPORT; BACK SIDE
6 1 572050980100 PANEL; BACK SIDE W/O PP
7 1 572050990100 PANEL; BACK SIDE W/O PP
8 1 572050900100 PANEL; FRONT SIDE
9 2 572054550100 PANEL; LEFT SIDE
Table 9. Kit contents LVR01092
# Qty Per Component Part Component Description
1 2 572095380100 SUPPORT; LOUVER
2 84 X25020604010 SCREW;M8 X 1.25MM X 16MM
3 8 572055590100 LOUVER; UNIT SIDE CGAM
4 1 572051000100 PANEL; BACK SIDE
5 1 572095690100 SUPPORT; BACK SIDE
6 1 572050980100 PANEL; BACK SIDE W/O PP
7 1 572050990100 PANEL; BACK SIDE W/O PP
8 1 572050900100 PANEL; FRONT SIDE
9 1 572054550100 PANEL; LEFT SIDE
10 1 572054610100 PANEL; LEFT SIDE W/PHR
Table 10. Kit contents LVR01093
# Qty Per Component Part Component Description
1 2 572095380100 SUPPORT; LOUVER
2 90 X25020604010 SCREW;M8 X 1.25MM X 16MM
3 8 572055590100 LOUVER; UNIT SIDE CGAM
4 1 572051000100 PANEL; BACK SIDE
5 1 572095690100 SUPPORT; BACK SIDE
6 1 572050980100 PANEL; BACK SIDE W/O PP
7 1 572050990100 PANEL; BACK SIDE W/O PP
9 1 572054550100 PANEL; LEFT SIDE
10 1 572054610100 PANEL; LEFT SIDE W/PHR
11 1 572097020100 PANEL; FRONT SIDE W/VFD
12 1
572097030100 PANEL; FRONT SIDE W/VFD
13 1 572097010100 SUPPORT; FRONT SIDE
Table 11. Kit contents LVR01094
# Qty Per Component Part Component Description
1 2 572095380100 SUPPORT; LOUVER
2 92 X25020604010 SCREW;M8 X 1.25MM X 16MM
3 8 572055590100 LOUVER; UNIT SIDE CGAM
4 1 572051000100 PANEL; BACK SIDE
5 1 572095690100 SUPPORT; BACK SIDE
6 1 572050910100 PANEL; BACK SIDE W/PP
7 1 572097980100 PANEL; BACK SIDE W/PP
9 1 572054550100 PANEL; LEFT SIDE
10 1 572054610100 PANEL; LEFT SIDE W/PHR
11 1 572097020100 PANEL; FRONT SIDE W/VFD
12 1 572097030100 PANEL; FRONT SIDE W/VFD
13 1 572097010100 SUPPORT; FRONT SIDE
Table 12. Kit contents LVR01095
# Qty Per Component Part Component Description
1 2 572095380100 SUPPORT; LOUVER
2 86 X25020604010 SCREW;M8 X 1.25MM X 16MM
3 8 572055590100 LOUVER; UNIT SIDE CGAM
4 1 572051000100 PANEL; BACK SIDE
5 1 572095690100 SUPPORT; BACK SIDE
6 1 572050910100 PANEL; BACK SIDE W/PP
7 1 572097980100 PANEL; BACK SIDE W/PP
8 1 572050900100 PANEL; FRONT SIDE
9 1 572054550100 PANEL; LEFT SIDE
10 1 572054550100 PANEL; LEFT SIDE
Table 13. Kit contents LVR01096
# Qty Per Component Part Component Description
1 2 572095380100 SUPPORT; LOUVER
2 92 X25020604010 SCREW;M8 X 1.25MM X 16MM
3 8 572055590100 LOUVER; UNIT SIDE CGAM
4 1 572051000100 PANEL; BACK SIDE
5 1 572095690100 SUPPORT; BACK SIDE
6 1 572050910100 PANEL; BACK SIDE W/PP
7
1 572097980100 PANEL; BACK SIDE W/PP
9 1 572054550100 PANEL; LEFT SIDE
10 1 572054550100 PANEL; LEFT SIDE
11 1 572097020100 PANEL; FRONT SIDE W/VFD
12 1 572097030100 PANEL; FRONT SIDE W/VFD
13 1 572097010100 SUPPORT; FRONT SIDE
