Trane CGAM020 User Manual

6 PART-SVN228B-EN
Installation
WARNING
Hazardous Voltage!
Failure to disconnect power before servicing could
result in death or serious injury. Disconnect all electric
power, including remote disconnects before servicing.
Follow proper lockout/tagout procedures to ensure the
power can not be inadvertently energized.
NOTICE
Equipment Damage!
Using an impact gun when installing plastic louvers
could result in equipment damage. Do NOT use an
impact gun when installing plastic louvers.
CGAM020 and CGAM026 Chillers
(S1, Slant Units)
Table 2. Kit number FMF14536
# Qty Per Component Part Component Description
1 2 572095370100 PANEL; LOUVER
2 1 572095360100 SUPPORT; LOUVER
3 70 X25020604010 SCREW;M8 X 1.25MM X 16MM
4 8 X25030266010 SCREW; M6 X 16MM HEX CAP
5 6 572055590100 LOUVER; UNIT SIDE CGAM
6 1 572051000100 PANEL; BACK SIDE
7 1 572095690100 SUPPORT; BACK SIDE
8 1 572050990100 PANEL; BACK SIDE W/O PP
9 1 572050980100 PANEL; BACK SIDE W/O PP
10 2 572054540100 PANEL; LEFT SIDE
11 1 572050900100 PANEL; FRONT SIDE
Table 3. Kit number LVR01087
# Qty Per Component Part Component Description
1 2 572095370100 PANEL; LOUVER
2 1 572095360100 SUPPORT; LOUVER
3 72 X25020604010 SCREW;M8 X 1.25MM X 16MM
4 8 X25030266010 SCREW; M6 X 16MM HEX CAP
5 6 572055590100 LOUVER; UNIT SIDE CGAM
6 1 572051000100 PANEL; BACK SIDE
7 1 572095690100 SUPPORT; BACK SIDE
8 1 572050990100 PANEL; BACK SIDE W/O PP
9 1 572050980100 PANEL; BACK SIDE W/O PP
10 1 572054540100 PANEL; LEFT SIDE
11 1 572050900100 PANEL; FRONT SIDE
12 1 572054620100 PANEL; LEFT SIDE W/PHR
13 1 572054630100 PANEL; LEFT SIDE W/PHR
Table 4. Kit number LVR01088
# Qty Per Component Part Component Description
1 2 572095370100 PANEL; LOUVER
2 1 572095360100 SUPPORT; LOUVER
3 78 X25020604010 SCREW;M8 X 1.25MM X 16MM
4 8 X25030266010 SCREW; M6 X 16MM HEX CAP
5 6 572055590100 LOUVER; UNIT SIDE CGAM
6 1 572051000100 PANEL; BACK SIDE
7 1 572095690100 SUPPORT; BACK SIDE
8 1 572050990100 PANEL; BACK SIDE W/O PP
9 1 572050980100 PANEL; BACK SIDE W/O PP
10 1 572054540100 PANEL; LEFT SIDE
12 1 572054620100 PANEL; LEFT SIDE W/PHR
13 1 572054630100 PANEL; LEFT SIDE W/PHR
14 1 572097020100 PANEL; FRONT SIDE W/VFD
15 1 572097030100 PANEL; FRONT SIDE W/VFD
16 1 572097010100 SUPPORT; FRONT SIDE
Table 5. Kit number LVR01089
# Qty Per Component Part Component Description
1 2 572095370100 PANEL; LOUVER
2 1 572095360100 SUPPORT; LOUVER
3 80 X25020604010 SCREW;M8 X 1.25MM X 16MM
4 8 X25030266010 SCREW; M6 X 16MM HEX CAP
5 6 572055590100 LOUVER; UNIT SIDE CGAM
6 1 572051000100 PANEL; BACK SIDE
7 1 572095690100 SUPPORT; BACK SIDE
8 1 572097980100 PANEL; BACK SIDE W/PP
9 1 572050910100 PANEL; BACK SIDE W/PP
10 1 572054540100 PANEL; LEFT SIDE
12 1 572054620100 PANEL; LEFT SIDE W/PHR
13 1 572054630100 PANEL; LEFT SIDE W/PHR
14 1 572097020100 PANEL; FRONT SIDE W/VFD
15 1 572097030100 PANEL; FRONT SIDE W/VFD
16 1 572097010100 SUPPORT; FRONT SIDE
