Installation
14 PART-SVN228B-EN
CGAM040 and CGAM052 Chillers
(V1 Units)
Table 14. Kit contents FMF14437
(a)
(a) CGAM040 chillers only.
# Qty Per Component Part Component Description
1 4 572095370100 PANEL; LOUVER
2 16 X25030266010 SCREW; M6 X 16MM HEX CAP
3 2 572095360100 SUPPORT; LOUVER
4 131 X25020604010 SCREW;M8 X 1.25MM X 16MM
5 12 572055590100 LOUVER; UNIT SIDE CGAM
6 1 572116120100 SUPPORT; LOUVER
7 1 572094890100 POST; LOUVER
8 2 572055570100 LOUVER; LOWER END CGAM
9 1 572116160100 PANEL; TOP CONTROL PANEL
10 1 572116130100 SUPPORT; PANEL
11 1 572116010100 SUPPORT; PHR
12 3 572116030100 PANEL; UNIT END
13 1 572116090100 PANEL; BPHE INLET/OUTLET
14 1 572116080100 PANEL; BPHE INLET/OUTLET
Table 15. Kit contents LVR01097
(a)
(a) CGAM052 chillers only.
# Qty Per Component Part Component Description
1 4 572095370100 PANEL; LOUVER
2 16 X25030266010 SCREW; M6 X 16MM HEX CAP
3 2 572095360100 SUPPORT; LOUVER
4 131 X25020604010 SCREW;M8 X 1.25MM X 16MM
5 12 572055590100 LOUVER; UNIT SIDE CGAM
6 1 572116120100 SUPPORT; LOUVER
7 1 572094890100 POST; LOUVER
8 2 572055570100 LOUVER; LOWER END CGAM
9 1 572116160100 PANEL; TOP CONTROL PANEL
10 1 572116130100 SUPPORT; PANEL
11 1 572116010100 SUPPORT; PHR
12 1 572116030100 PANEL; UNIT END
13 1 572116070100 PANEL; UNIT END
14 1 572116080100 PANEL; BPHE INLET/OUTLET
15 1 572116030100 PANEL; UNIT END
16 1 572116030100
PANEL; UNIT END
Table 16. Kit contents LVR01098
# Qty Per Component Part Component Description
1 4 572095370100 PANEL; LOUVER
2 16 X25030266010 SCREW; M6 X 16MM HEX CAP
3 2 572095360100 SUPPORT; LOUVER
4 131 X25020604010 SCREW;M8 X 1.25MM X 16MM
5 12 572055590100 LOUVER; UNIT SIDE CGAM
6 1 572116120100 SUPPORT; LOUVER
7 1 572094890100 POST; LOUVER
8 2 572055570100 LOUVER; LOWER END CGAM
9 1 572116160100 PANEL; TOP CONTROL PANEL
10 1 572116130100 SUPPORT; PANEL
11 1 572116010100 SUPPORT; PHR
12 1 573120610100 PANEL; UNIT END, V UNIT
13 1 572116050100 PANEL; UNIT END
14 1 572116060100 PANEL; UNIT END
15 1 572116030100 PANEL; UNIT END
16 1 572116030100 PANEL; UNIT END
Table 17. Kit contents LVR01099
# Qty Per Component Part Component Description
1 4 572095370100 PANEL; LOUVER
2 16 X25030266010 SCREW; M6 X 16MM HEX CAP
3 2 572095360100 SUPPORT; LOUVER
4 127 X25020604010 SCREW;M8 X 1.25MM X 16MM
5 12 572055590100 LOUVER; UNIT SIDE CGAM
6 1 572116120100 SUPPORT; LOUVER
7 1 572094890100 POST; LOUVER
8 2 572055570100 LOUVER; LOWER END CGAM
9 1 572116160100 PANEL; TOP CONTROL PANEL
10 1 572116130100 SUPPORT; PANEL
12 1 572116030100 PANEL; UNIT END
13 1 572116090100 PANEL; BPHE INLET/OUTLET
14 1 572116080100 PANEL; BPHE INLET/OUTLET
15 1 572116100100 PANEL; PHR INLET/OUTLET
16 1 572116110100
PANEL; UNIT END
