Trane GAF2A0A30S21EE User Manual

7
STEP 3 - Slide Blower assembly out of unit using
built-in blower support channels and set aside.
Note: Remove the cardboard from the bottom of the
blower. Cut the tie wrap and remove the foam block
located at the motor.
Blower Support
Channel
STEP 4 - Slide the Coil assembly out of unit using
built-in coil support channels and set aside.
Coil Support
Channel

Trane GAF2A0A30S21EE Specifications

General

Brand	Trane
Model	GAF2A0A30S21EE
Category	Air Handlers
Language	English
