STEP 5 - For extremely tight spaces where the

cabinet needs to be rotated through a small

opening, remove the top panel and all cross

members. Use a manual driver to avoid stripping

screw holes.

Note: Cross Members are removed by rotating

them toward the door opening and then lifting up

and out of the unit.

Note - When carrying the air handler to the

install location, be sure to use approved carrying

procedures shown in Section 5, if needed.
