Trane IntelliPak Signature Series Programming Guide

44
Programming
PKG-SVP01B-EN
(On units with a VOM and IGV or VFD)
Ventilation Override Definition Mode A
Supply Fan ON
Factory Presets: Refer to definitions on page 5.
Possible Values: On, Off
1. Pressing the NEXT key will display the following screen.
(On units with a VOM and airside or waterside economizer)
Ventilation Override Definition Mode A
Outside Air Dampers OPEN
Factory Presets: Refer to definitions on page 5.
Possible Values: Open, Closed
1. Pressing the NEXT key will display the following screen.
(On units with a VOM and electric or hydronic heat)
Ventilation Override Definition Mode A
Heat OFF
Factory Presets: Refer to definitions on page 5.
Possible Values: Off, In Control
1. Pressing the NEXT key will display the following screen.
(On units with a VOM)
Ventilation Override Definition Mode A
VAV Box Relay DEENERGIZED
Factory Presets: Refer to definitions on page 5.
Possible Values: Energized, Deenergized
1. Pressing the NEXT key will display the following screen.
(On units with a VOM installed and OA preheater function enabled)
Ventilation Override Definition Mode A
OA Preheater State IN CONTROL
Factory Presets: Refer to definitions on page 5.
Possible Values: In Control, Off
1. Pressing the NEXT key will display the following screen.
(On units with a VOM )
Ventilation Override Definition Mode A
VO Relay ENERGIZED
Factory Presets: Refer to definitions on page 5.
Possible Values: Energized, Deenergized
1. Pressing the NEXT key will display the following screen.
SETUP
