PKG-SVP01B-EN
45
Programming
(On units with a VOM
)
Ventilation Override Definition Mode A
Enter Password to Lock Definition:
Factory Presets: Refer to definitions on page 5.
Possible Values: + (Plus), - (Minus)
1. Pressing the NEXT key will display the following screen.
Note: After lock a MODE (by entering the password), the display for that MODE becomes
“reporting” only and the definition cannot be changed unless the VOM is replaced. After
entering the password, press the NEXT key to scroll through the previous screens to
confirm selected choices for each mode as follows below.
(On units with a VOM and VO mode locked)
Ventilation Override Mode A Is Locked
Supply Fan
Factory Presets: Refer to definitions on page 5.
1. Pressing the NEXT key will display the following screen.
(On units with a VOM)
Ventilation Override Mode B
Supply Fan
Follow the preceding steps used to program MODE “A” to program MODES “B,” “C,”
“D,” and “E” as needed.
1. Pressing the NEXT key will display the following screen.
End of Submenu (NEXT) to Enter SETUP
1. Pressing the NEXT key will display the following screen.
GBAS Module I/O Assignments
(On units with a GBAS)
GBAS 0 - 5VDC Module I/O Assignments
Press ENTER to Review or Adjust
1. Pressing the NEXT key will display the following screen.
SETUP
To Next Page
