Trane IntelliPak Signature Series Programming Guide

48
Programming
PKG-SVP01B-EN
SETUP
Temperature Input Calibration
The following calibration and offset
screens allow sensor calibration, when
necessary.
For example, if using the MWU sensor
and you detect a difference between the
actual measured room temperature and
the corresponding measured sensor
value, the sensor needs calibration. Using
the temperatuare input calibration screen
for MWU heat, program the error
amount into the Temperature Input Offset
field to calibrate the sensor.
To change offset values on a particular
screen:
1. Press the plus or minus key until the
correct value appears in the screen.
2. Press the ENTER key to confirm your
choice. If you’ve made an error, press
the CANCEL key to delete your entry.
To navigate to another screen:
1. Press the NEXT key to advance to the
next screen, OR
a. if no further changes are required and
you want to exit back to view the unit
operating status, press the STATUS key
once, OR
b. if you want to remain in the tempera-
ture input calibration submenu, press
the SETUP key once and it will return
you to the beginning of that particular
submenu, OR
c. if you want to exit to another submenu
in the SETUP menu, press the SETUP
key twice. Then press the NEXT key to
scroll through the SETUP submenu
choices, OR
d. if you want to exit to another menu,
such as CONFIGURATION, press that
key once, then press the NEXT key to
scroll through those screens.
Temperature Input Calibration Screens
(Applicable to All Units)
Calibration and Offset Submenu
Press ENTER to Review or Adjust
1. Press the NEXT key to bypass this section or press the ENTER key to view the
following screens.
Temperature Calibration Offset For
RTM Zone Temperature Input 0.0 F
Factory Preset: 0.0 F
Possible Values: Plus or Minus 5.0 F
1. Pressing the NEXT key will display the following screen.
Temperature Calibration Offset For
RTM Aux Temperature Input 0.0 F
Factory Preset: 0.0 F
Possible Values: Plus or Minus 5.0 F
1. Pressing the NEXT key will display the following screen.
Temperature Calibration Offset For
RTM Outside Air Temperature Input 0.0 F
Factory Preset: 0.0 F
Possible Values: Plus or Minus 5.0 F
1. Pressing the NEXT key will display the following screen.
(On units with electric or hydronic heat only)
Temperature Calibration Offset For
Heat Module Aux Temp Input 0.0 F
Factory Preset: 0.0 F
Possible Values: Plus or Minus 5.0 F
1. Pressing the NEXT key will display the following screen.
(On units with comparative enthalpy installed)
Temperature Calibration Offset For
ECEM Return Air Temperature Input 0.0 F
Factory Preset: 0.0 F
Possible Values: Plus or Minus 5.0 F
1. Pressing the NEXT key will display the following screen.
