Trane IntelliPak Signature Series Programming Guide

PKG-SVP01B-EN
53
Programming
SETUP
(On units with a waterside economizer)
Actuator Setup Water Econ Bypass
Direct/Reverse Acting DIRECT ACTING
Factory Presets: Direct Acting
Possible Values: Direct Acting, Reverse Acting
1. Pressing the NEXT key will display the following screen.
(On units with IGV or VFD)
Actuator Setup IGV/VFD Cmd
Max Stroke Time 150 Sec
Factory Presets: 150 Sec
Possible Values: 1-255 Sec
1. Pressing the NEXT key will display the following screen.
(On units with IGV or VFD)
Actuator Setup IGV/VFD Cmd
Min Voltage 2.0 VDC
Factory Presets: 2.0 VDC
Possible Values: 0-10 VDC
1. Pressing the NEXT key will display the following screen.
(On units with IGV or VFD)
Actuator Setup IGV/VFD Cmd
Max Voltage 10.0 VDC
Factory Presets: 10.0 VDC
Possible Values: 0-10 VDC
1. Pressing the NEXT key will display the following screen.
(On units with IGV or VFD)
Actuator Setup IGV/VFD Cmd
Direct/Reverse Act DIRECT ACTING
Factory Presets: Direct Acting
Possible Values: Direct Acting, Reverse Acting
1. Pressing the NEXT key will display the following screen.
(On units with hydronic heat)
Actuator Setup Hydronic
Max Stroke Time 150 Sec
Factory Presets: 150 Sec
Possible Values: 1-255 Sec
1. Pressing the NEXT key will display the following screen.
