Trane IntelliPak Signature Series Programming Guide

54
Programming
PKG-SVP01B-EN
(On units with hydronic heat)
Actuator Setup Hydronic
Min Voltage 2.0 VDC
Factory Presets: 2.0 VDC
Possible Values: 0.0-9.9 VDC
1. Pressing the NEXT key will display the following screen.
(On units with hydronic heat)
Actuator Setup Hydronic
Max Voltage 10.0 VDC
Factory Presets: 10.0 VDC
Possible Values: 0.1-10.0 VDC
1. Pressing the NEXT key will display the following screen.
(On units with hydronic heat)
Actuator Setup Hydronic
Direct/Reverse Act DIRECT ACTING
Factory Presets: Direct Acting
Possible Values: Direct Acting, Reverse Acting
1. Pressing the NEXT key will display the following screen.
(On air-cooled units with low ambient damper)
Actuator Setup Num 1 Low Ambient
Max Stroke Time 60 Sec
Factory Presets: 60 Sec
Possible Values: 1-255 Sec
1. Pressing the NEXT key will display the following screen.
(On air-cooled units with low ambient damper)
Actuator Setup Num 1 Low Ambient
Min Voltage 2.0 VDC
Factory Presets: 2.0 VDC
Possible Values: 0.0-9.9 VDC
1. Pressing the NEXT key will display the following screen.
(On air-cooled units with low ambient damper)
Actuator Setup Num 1 Low Ambient
Max Voltage 10.0 VDC
Factory Presets: 10.0 VDC
Possible Values: 0.1-10.0 VDC
1. Pressing the NEXT key will display the following screen.
SETUP
