Trane IntelliPak Signature Series User Manual

SCXF-SVX01B-EN 17
Dimensions
and WeightsInstallation
Detail A
Electrical Connections
Discharge Dimensions - English - (inches)
Unit Tons A B C D
20-38 Tons 30
3
/
8
26
1
/
8
21
1
/
4
25
3
/
4
40-80 Tons 43
1
/
2
33 31
1
/
2
31
1
/
2
Discharge Dimensions - Metric - (mm)
Unit Tons A B C D
20-38 Tons 772 664 540 654
40-80 Tons 1105 838 800 800
40 3/8” (20-38 Ton)
1026 mm (20-38 Ton)

Trane IntelliPak Signature Series Specifications

General

Brand	Trane
Model	IntelliPak Signature Series
Category	Air Conditioner
Language	English
