Trane IntelliPak Signature Series User Manual

6 SCXF-SVX01B-EN
Installation
Sample Unit Model Number:
S C W F N 20 4 2 BO A B 2 10 065 B A 1 0 1 0 A A C F A 1 1 0 T 2 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
Model Number Description
Each IntelliPak
®
self-contained unit has a multiple character model number unique to that unit. To determine a unit’s specific options,
reference the model number on the unit nameplate using the model number explanation below.
Digit 1 - Unit Model
S = Self Contained
Digit 2 - Unit Type
C = Commercial
I = Industrial
Digit 3 - Condenser Medium
W = Water-Cooled
R = Air-Cooled
Digit 4 - Development Sequence
F = F
Digit 5 - Refrigerant Circuit Configuration
N = Independent (Water-Cooled)
M = Manifolded (Air-Cooled)
Digit 6, 7 - Unit Nominal Capacity
20 = 20 Tons (Water or Air)
22 = 22 Tons (Water Only)
25 = 25 Tons (Water or Air)
29 = 29 Tons (Water or Air)
30 = 30 Tons (Air Only)
32 = 32 Tons (Water Only)
35 = 35 Tons (Water or Air)
38 = 38 Tons (Water Only)
40 = 40 Tons (Air Only)
42 = 42 Tons (Water Only)
46 = 46 Tons (Water Only)
50 = 50 Tons (Air Only)
52 = 52 Tons (Water Only)
58 = 58 Tons (Water Only)
60 = 60 Tons (Air Only)
65 = 65 Tons (Water Only)
72 = 72 Tons (Water Only)
80 = 80 Tons (Water Only)
Digit 8 - Unit Voltage
6 = 200 Volt/60 Hz/3 ph
4 = 460 Volt/60 Hz/3 ph
5 = 575 Volt/60 Hz/3 ph
Digit 9 - Air Volume/Temp Control
1 = IGV and Supply Air Temp Ctrl
2 = Variable Frequency Drive and Supply
Air Temp Ctrl
3 = Variable Frequency Drive w/ Bypass
and Supply Air Temp Ctrl
4 = w/o Vol. CTRL, w/ Zone Temp Cool
5 = w/o Vol. CTRL, w/ Zone Temp Heat/Cool
6 = w/o Vol. CTRL, w/ Supply Air Temp Ctrl
Digit 10, 11 - Design Sequence
BO = “B” Design
Digit 12 - Unit Construction
A = Vertical Discharge
B = Vertical Discharge with Double Wall
C = Horizontal Discharge
D = Horizontal Discharge w/ Double Wall
Digit 13 - Flexible Horizontal Discharge
Plenum Type
B = Std (33”) Plenum w/Factory Cut Holes
C = Low Plenum (24”) w/Factory Cut
Holes
E = Std Plenum w/ Field Cut Holes
F = Low Plenum w/ Field Cut Holes
H = Std Plenum Double wall w/ Field Cut
Holes
J = Low Plenum Double wall w/ Field Cut
Holes
K = 45” Plenum w/Factory Cut Holes,
Ship Separate
L = Std Plenum w/Factory Cut Holes, Ship
Separate
M = Low Plenum w/Factory Cut Holes,
Ship Separate
N = 45” Plenum w/Field Cut Holes, Ship
Separate
P = Std Plenum w/Field Cut Holes, Ship
Separate
R = Low Plenum w/Field Cut Holes, Ship
Separate
T = 45” Double Wall Plenum w/Field Cut
Holes, Ship Separate
U = Std Double Wall Plenum w/Field Cut
Holes, Ship Separate
V = Low Double Wall Plenum w/Field
Cut Holes, Ship Separate
0 = None
Digit 14 - Motor Type
1 = Std Eff. ODP Motor
2 = High Eff. ODP Motor
3 = Totally Enclosed Motor
Digit 15, 16 - Motor HP
05 = 5 HP Motor
07 = 7.5 HP Motor
10 = 10 HP Motor
15 = 15 HP Motor
20 = 20 HP Motor
25 = 25 HP Motor
30 = 30 HP Motor
40 = 40 HP Motor
50 = 50 HP Motor, 460V & 575V ODP Only
Digit 17, 18, 19 - Fan RPM
040 = 400 rpm
045 = 450 rpm
050 = 500 rpm
055 = 550 rpm
060 = 600 rpm
065 = 650 rpm
070 = 700 rpm
075 = 750 rpm
080 = 800 rpm
085 = 850 rpm
090 = 900 rpm
095 = 950 rpm
100 = 1000 rpm
105 = 1050 rpm
110 = 1100 rpm
115 = 1150 rpm
120 = 1200 rpm
125 = 1250 rpm
130 = 1300 rpm
135 = 1350 rpm
140 = 1400 rpm
145 = 1450 rpm
150 = 1500 rpm
Digit 20 - Heating Type
A = Steam Coil
B = Hot Water Coil
C = Electric Heat (1 Stage)
F = Hydronic Heat Ctrl Interface
G = Elec. Heat Ctrl Interface (1 stage)
K = Steam Coil Ship Separate
L = Hot Water Coil Ship Separate
0 = Without Heat
Digit 21 - Unit Isolators
A = Isopads
B = Spring Isolators
0 = None
Digit 22 - Unit Finish
1 = Paint - Executive Beige
General
Information
