Trane IntelliPak with Symbio 800 - Page 19

RT-SVX063G-EN
19
Figure 4. 40 to 55 ton — left view of sample configuration (inches)
79.33
81.59
87.66
300.88
LEFT SIDE VIEW
40-55T / ELECT. HT. / CART. FILTERS
Figure 5. 60 to 75 ton — front view (inches)
27.32
40.38
116.13
FRONT VIEW
60-75T
Dimensional Data
