Trane Startup Checklist
This checklist is intended to be a guide for the Trane
technician just prior to unit 'startup'. Many of the
recommended checks and actions could expose the
technician to electrical and mechanical hazards. Refer to
the appropriate sections in the this manual for appropriate
procedures, component specifications and safety
instructions.
Important: This checklist is not intended as a substitution
for the contractor’s installation instruction.
Important: Except where noted, it is implied that the Trane
technician is to use this checklist for
inspection/verification of prior tasks completed
by the general contractor at installation. Use
the line item content to also record the
associated values onto the Trane unitary
packaged equipment log.
Job Name Serial #
Job Location Model #
Sales Order # Ship Date
Unit DL # (special units) Date
Starting Sales Office Technician
Table 27. Startup checklist
Completed?
General Start-up
1
Is adequate access/egress provided?
Yes No
2
Initial site inspection performed?
Yes No
3
Unit exterior inspected for damage (dents, bends, missing panels, doors work properly)?
Yes No
4
Unit clearances adequate to avoid air recirculation?
Yes No
5
Verify crankcase heaters are working and on for 8 hours prior to unit start
Yes No
6
Verify unit interior is free from debris and obstructions, etc.
Yes No
7
All unit drain lines and traps are properly installed
Yes No
8
Verify unit is grounded. Confirm a ground wire is coming from the power source
Yes No
9
Verify main power feed wire gauge is properly sized for current load
Yes No
10
Verify all wiring connections are tight
Yes No
11
Verify all field control wiring for CV, SZVAV or VAV controls are complete
Yes No
12
Verify hold down bolts from fan sections removed
Yes No
13
Fan section isolators checked/adjusted (approximately ¼” gap above shipping block)
Yes No
14
Verify compressor oil levels at proper levels
Yes No
15
Compressor discharge service valves and optional suction service valves open/back seated
Yes No
16
Verify fans rotate freely
Yes No
17
Verify refrigerant charge on each circuit
Yes No
18
Verify correct voltage supplied to unit and electrical heaters
Yes No
19
Verify there are no unit phase monitor errors.
Yes No
20
Verify all fans rotate in proper direction
Yes No
21
Verify fan amperages within nameplate specs (please document on log sheet)
Yes No
Unit Configuration and Setup
1
Verify model number in the UCM configuration matches unit model number on nameplate
Yes No
2
Configure unit using IOM and critical control parameters using critical control parameters table
Yes No
Air Cooled Condenser
1
All coil fins inspected and straightened
Yes No
2
Condenser fans are rotating freely
Yes No
3
Verify the fan blade set-screws to the motor shaft of the condenser fan assemblies are tight
Yes No
Outside Air and Economizer (if applicable)
1
Verify damper linkages are tight/adjusted and tip seals are in good condition
Yes No
2
Outside air pressure sensor installed and tubing connected to fitting on unit exterior
Yes No
3
Duct pressure tubing connected to duct pressure sensor
Yes No
4
Tubing from controlled space connected to space pressure fitting (StatiTrac)
Yes No
Electric Heat (if applicable)
