Trane IntelliPak with Symbio 800 User Manual

RT-SVX063G-EN
99
Relief Fan Curves
Please see notes below for all supply fan curves. For
additional information or support, contact your local Trane
sales office or Trane representative.
Important:
1. Shaded area represents selectable area.
Contact your local Trane representative for
more information.
2. Relief fan performance curve includes
internal resistance of rooftop. To determine
total static pressure, add return static
pressure and relief damper pressure drop.
3. EC motors are not offered in integral
horsepower increments. All fans will be
offered with nominal motor power rated to
cover the operating envelope of the fan.
Power limitation is indicated on fan map.
Figure 54. 20 to 25 ton, 6 hp relief fan, single fan
1900 RPM
1800 RPM
1700 RPM
1600 RPM
1500 RPM
1400 RPM
1300 RPM
1200 RPM
1100 RPM
1000 RPM
900 RPM
1980 RPM
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000
Sta!c Pressure, Inches w.c.
Airflow, CFM
Figure 55. 20 ton, 8 hp relief fan, single fan
2000 RPM
1900 RPM
1800 RPM
1700 RPM
1600 RPM
1500 RPM
1400 RPM
1300 RPM
1200
RPM
1100
RPM
900 RPM
1000 RPM
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000
Sta!c Pressure, Inches w.c.
Airflow, CFM
Figure 56. 30 ton, 12 hp relief fan, two-fan array
1980 RPM
1900 RPM
1800 RPM
1700 RPM
1600 RPM
1500 RPM
1400 RPM
1300 RPM
1200 RPM
1100 RPM
1000 RPM
900 RPM
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000 13000 14000 15000
Sta!c Pressure, Inches w.c.
Airflow, CFM
Figure 57. 25, 30 and 40 ton, 8 hp relief fan, single fan
1800 RPM
1700 RPM
1600 RPM
1500 RPM
1400 RPM
1300 RPM
1200 RPM
1100 RPM
1000 RPM
900 RPM
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000
Sta!c Pressure, Inches w.c.
Airflow, CFM
Figure 58. 40 ton, 15 hp relief fan, two-fan array
2000 RPM
1800 RPM
1700 RPM
1600 RPM
1500 RPM
1400 RPM
1300 RPM
1200 RPM
1100 RPM
1000 RPM
900 RPM
1900 RPM
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000 13000 14000 15000 16000 17000 18000 19000 20000
Sta!c Pressure, Inches w.c.
Airflow, CFM
Performance Data
