Trane IntelliPak with Symbio 800 User Manual

RT-SVX063G-EN
25
Access Clearances
Figure 11. Minimum access clearances – 20 to 30 ton
OUTSIDE AIR
CONTROL BOX
ELECTRIC HEAT
CONTROL BOX
RELIEF FANS
HOOD
ECONOMIZER
PRE-FILTER
EVAPORATOR COIL
ELECTRIC HEAT
CONTROL BOX
SUPPLY FAN
SUPPLY FAN
CB
VFD
CB
PB
18"
19.5"
25.5
20"
25.5"
18.5"
20.5"
26.5"
32"
PLAN VIEW
20-30T DOOR LAYOUT
SUPPLY FAN
CONTROL BOX
POWER
BOX
20"
Figure 12. Minimum access clearances – 40 to 55 ton
OUTSIDE AIR
CONTROL BOX
SUPPLY FAN
CONTROL BOX
GAS HEAT
CONTROL BOX
RELIEF FANS
HOOD
ECONOMIZER
PRE-FILTER
EVAPORATOR COIL
GAS HEAT
CONTROL BOX
SUPPLY FAN
SUPPLY FAN
CB
VFD
CB
PB
25.5"
19.5"
25.5"
20"
25.5"
16.5"
20.5"
26.5"
32"
PLAN VIEW
40-55T DOOR LAYOUT
POWER
BOX
Dimensional Data
