Trane IntelliPak with Symbio 800 User Manual

52
RT-SVX063G-EN
Table 19. Outside air damper pressure drop — Traq™
Traq™
CFM
Outside Air Damper Position
#1 #2 #3 #4 #5 #6
20, 25 and 30 Ton
4000 0.07 0.08 0.09 0.17 0.26 0.89
6000 0.15 0.18 0.21 0.40 0.64 2.82
7000 0.20 0.26 0.31 0.56 0.90 -
8000 0.26 0.35 0.43 0.73 1.19 -
9000 0.32 0.45 0.56 0.93 1.53 -
10000 0.40 0.57 0.71 1.15 1.91 -
11000 0.47 0.70 0.88 1.40 2.33 -
12000 0.56 0.85 1.06 1.67 2.79 -
13000 0.65 1.01 1.27 1.97 - -
40, 50 and 55 Ton
8000 0.23 0.40 0.46 0.89 1.75 -
10000 0.35 0.56 0.65 1.33 2.57 -
12000 0.49 0.73 0.86 1.85 - -
14000 0.66 0.93 1.11 2.45 - -
16000 0.85 1.15 1.38 - - -
18000 1.07 1.39 1.68 - - -
20000 1.31 1.64 2.00 - - -
22000 1.57 1.92 2.36 - - -
24000 1.86 2.23 2.74 - - -
Table 20. Return air pressure increase
CFM
Return Air Damper Position
#1 #2 #3 #4
20, 25 and 30 Ton
4000 0.00 0.01 0.06 0.06
6000 0.00 0.02 0.09 0.14
7000 0.00 0.03 0.11 0.19
8000 0.00 0.03 0.13 0.25
9000 0.00 0.04 0.14 0.31
10000 0.00 0.04 0.16 0.38
11000 0.00 0.05 0.18 0.46
12000 0.00 0.05 0.20 0.55
13000 0.00 0.06 0.22 0.65
40, 50 and 55 Ton
8000 0.00 0.07 0.15 0.17
10000 0.00 0.09 0.19 0.24
12000 0.00 0.10 0.22 0.33
Installation
