RT-SVX063G-EN
55
Figure 32. Actuator stroke limit adjustment
9
Philips screwdriver
Angle of Rotation
Limiter
Scale Shows % of
Full Stroke
Figure 33. Actuator auto-scaling feature details
Control Reversing Switch
Must Be Set to Match Spring
Return Direction
Installation
