94
RT-SVX063G-EN
Table 42. Compressor staging 25S, 30S
Stage Comp 1A Comp 1B Comp 1C
1 ON
2 ON
3 ON ON
4 ON ON
5 ON ON ON
Table 43. Compressor staging 20H, 25H, 30H
Stage Comp 1A Comp 1B
1 ON
2 ON
3 ON ON
Table 44. Compressor staging 40S, 40H, 50S, 50H,
55S, 55H, 60S, 60H, 70S, 70H, 75S, 75H
Stage Comp 1A Comp 1B Comp 2A Comp 2B
1 ON
2 ON ON
3 ON ON ON
4 ON ON ON ON
Table 45. Compressor staging 20V
Capacity
Step
Comp 1A
(a)
Comp 1B Speed
Min
Speed
Max
1 ON 1500 5670
2 ON ON 1500 5190
(a)
Variable Speed Compressor.
Table 46. Compressor staging 25V
Capacity
Step
Comp 1A
(a)
Comp 1B Speed
Min
Speed
Max
1 ON 1620 6000
2 ON ON 1500 6000
(a)
Variable Speed Compressor.
Table 47. Compressor staging 30V
Capacity
Step
Comp 1A
(a)
Comp 1B Speed
Min
Speed
Max
1 ON 1500 6000
2 ON ON 1500 5010
(a)
Variable Speed Compressor.
Table 48. Compressor staging 40V
Capaci-
ty Step
Comp
1A
(a)
Comp
2A
Comp
2B
Speed
Min
Speed
Max
1 ON 1800 5202
2 ON ON 1998 5400
3 ON ON ON 2520 5940
(a)
Variable Speed Compressor.
Table 49. Compressor staging 50V
Capaci-
ty Step
Comp
1A
(a)
Comp
2A
Comp
2B
Speed
Min
Speed
Max
1 ON 1590 4500
2 ON ON 1500 4590
3 ON ON ON 2160 4590
(a)
Variable Speed Compressor.
Table 50. Compressor staging 55V
Capaci-
ty Step
Comp
1A
(a)
Comp
2A
Comp
2B
Speed
Min
Speed
Max
1 ON 1662 4380
2 ON ON 1500 4860
3 ON ON ON 2340 4860
(a)
Variable Speed Compressor.
Table 51. Compressor staging 60V
Capaci-
ty Step
Comp
1A
(a)
Comp
2A
Comp
2B
Speed
Min
Speed
Max
1 ON 1950 4980
2 ON ON 1500 5550
3 ON ON ON 2580 5550
(a)
Variable Speed Compressor.
Table 52. Compressor staging 70V
Capaci-
ty Step
Comp
1A
(a)
Comp
2A
Comp
2B
Speed
Min
Speed
Max
1 ON 2010 4860
2 ON ON 1500 4980
3 ON ON ON 2220 6000
(a)
Variable Speed Compressor.
Table 53. Compressor staging 75V
Ca-
pacity
Step
Comp
1A
(a)
Comp
1B
Comp
2A
Comp
2B
Speed
Min
Speed
Max
1 ON 2160 4680
2 ON ON 1590 4680
Controls
