28
GB
8.
SUPERVISORY
SYSTEM
7.
ENVIRONMENTALLY
FRIENDLY
REFRIGERANT
TEWI= m x L x n x GWP + ß x E x n + m x (1-∂) x GWP
refrigerant losses unit related factors unit efficiency maintenance recycle
Refrigerant Type ODP GWP TEWI(*)
R22 HCFC 0,05 1.700 1.968
RI34 HFC 0 1.300 1.821
R407C HFC 0 1.800 2.092
R410A HFC 0 1.900 1.756
Legenda:
m: refrigerant charge in kg
n: product lifespan in years
GWP: global warming potential in kg CO
2
ß: emission of CO
2
in the power plant for each kWh prodacad
E: annual energy recovery factor at end of life
∂: refrigerant recovery factor and of life
(∂=0.......on recovery; ∂=1....... total recovery)
(*) Per year, for each specific kW and considering total recovery at the end of the unit’s life [∂
As shown in the table below, using R410A means:
8. Supervisory System
JUPITER units have been developed and designed so that they can be inserted within a network which is managed
by a supervision system. They are therefore compatible with the most common external BMS (Building Management
Systems).
Compatibility with external BMS
BMS on serial networks
Modbus: No limit on the number of units connected, each one has a RS485 serial card
Bacnet: Max 8 units, each one has a RS485 serial card, connected to a Bacnet Gateway
LONworks: No limit on the number of units connected, each one has a FTT10 card
TREND: possible with TREND card
Metasys: possible with integration of the database and Application Note JCI
BMS on TCP/IP (UTP) networks
SNMP: Max 16 units, each one has a RS485 serial card, connected to a Webgate
SNMP: No limit on the number of units connected, each one has a TCP/IP (Pcoweb)
Bacnet: No limit on the number of units connected, each one has a TCP/IP
HTML: No limit on the number of units connected, each one has a TCP/IP
