PRESSIONE
STATICA DI
MANDATA IN
FUNZIONE ALLA
TENSIONE IN
ALIMENTAZIONE
DEI VENTILATORI
PRESSURE VS FANS
VOLTAGE SUPPLY
PRESSION
STATIQUE EN
FONCTION DE
LA TENSION
D’ALIMENTATION
JUDC0020* JUCV0020*
Portata aria [m
3
/h]
Airflow [m
3
/h]
Débit d’air [m
3
/h]
1040 1320 1520 1610 1816
Portata aria [m
3
/h]
Airflow [m
3
/h]
Débit d’air [m
3
/h]
1040 1400 1600 1800 2076
Velocità ventilatore
Fan Speed
Vitesse ventilateurs
Pressione statica di mandata
Available Static Pressure
Pressione statique externe disponibile
Velocità ventilatore
Fan Speed
Vitesse ventilateurs
Pressione statica di mandata
Available Static Pressure
Pressione statique externe disponibile
[%] [Pa] [Pa] [Pa] [Pa] [Pa] [%] [Pa] [Pa] [Pa] [Pa] [Pa]
51
20 - - - -
48
20 - - - -
60
154 5 - - -
67,6
238 102 20 - -
67
206 109 68 20 -
71
279 143 61 - -
75
225 168 139 104 -
80
382 246 164 86 -
100
235 202 183 159 20
85
441 305 223 146 20
JUCC0025* JUCV0025*
Portata aria [m
3
/h]
Airflow [m
3
/h]
Débit d’air [m
3
/h]
1150 1800 2000 2300 2445
Portata aria [m
3
/h]
Airflow [m
3
/h]
Débit d’air [m
3
/h]
1150 1500 1800 2000 2256
Velocità ventilatore
Fan Speed
Vitesse ventilateurs
Pressione statica di mandata
Available Static Pressure
Pressione statique externe disponibile
Velocità ventilatore
Fan Speed
Vitesse ventilateurs
Pressione statica di mandata
Available Static Pressure
Pressione statique externe disponibile
[%] [Pa] [Pa] [Pa] [Pa] [Pa] [%] [Pa] [Pa] [Pa] [Pa] [Pa]
52
20 - - - -
47
20 - - - -
60
158 - - - -
60
160 45 - - -
86
204 191 143 20 -
70
273 158 64 - -
90
201 196 157 54 -
80
390 275 180 113 -
100
241 198 163 78 20
85,2
452 336 242 174 20
JUCC0030* JUCV0030*
Portata aria [m
3
/h]
Airflow [m
3
/h]
Débit d’air [m
3
/h]
1150 1800 2000 2300 2422
Portata aria [m
3
/h]
Airflow [m
3
/h]
Débit d’air [m
3
/h]
1150 1500 1800 2000 2245
Velocità ventilatore
Fan Speed
Vitesse ventilateurs
Pressione statica di mandata
Available Static Pressure
Pressione statique externe disponibile
Velocità ventilatore
Fan Speed
Vitesse ventilateurs
Pressione statica di mandata
Available Static Pressure
Pressione statique externe disponibile
[%] [Pa] [Pa] [Pa] [Pa] [Pa] [%] [Pa] [Pa] [Pa] [Pa] [Pa]
52
20 - - - -
47
20 - - - -
60
156 - - - -
60
157 40 - - -
80
212 164 96 - -
70
271 154 58 - -
87
200 187 140 20 -
80
387 270 174 106 -
100
238 192 155 69 20
85,1
448 330 235 166 20
JUCC0040* JUCV0040*
Portata aria [m
3
/h]
Airflow [m
3
/h]
Débit d’air [m
3
/h]
1940 2500 3000 3350 3839
Portata aria [m
3
/h]
Airflow [m
3
/h]
Débit d’air [m
3
/h]
1940 2500 3350 3600 4000
Velocità ventilatore
Fan Speed
Vitesse ventilateurs
Pressione statica di mandata
Available Static Pressure
Pressione statique externe disponibile
Velocità ventilatore
Fan Speed
Vitesse ventilateurs
Pressione statica di mandata
Available Static Pressure
Pressione statique externe disponibile
[%] [Pa] [Pa] [Pa] [Pa] [Pa] [%] [Pa] [Pa] [Pa] [Pa] [Pa]
50
20 - - - -
47
19 - - - -
60
158 57 - - -
60
159 55 - - -
73
212 172 95 20 -
73
308 204 21 - -
90
201 193 150 102 15
80
389 285 102 49 -
100
219 202 155 106 20
85
448 344 161 108 17
JUCC0060* JUCV0060*
Portata aria [m
3
/h]
Airflow [m
3
/h]
Débit d’air [m
3
/h]
3000 3500 4000 4500 4625
Portata aria [m
3
/h]
Airflow [m
3
/h]
Débit d’air [m
3
/h]
3000 3700 4000 4500 4740
Velocità ventilatore
Fan Speed
Vitesse ventilateurs
Pressione statica di mandata
Available Static Pressure
Pressione statique externe disponibile
Velocità ventilatore
Fan Speed
Vitesse ventilateurs
Pressione statica di mandata
Available Static Pressure
Pressione statique externe disponibile
[%] [Pa] [Pa] [Pa] [Pa] [Pa] [%] [Pa] [Pa] [Pa] [Pa] [Pa]
61
20 - - - -
61
20 - - - -
70
146 49 - - -
70
111 - - - -
80
193 148 61 - -
84,1
277 151 95 1 -
89
192 168 113 20 -
90
331 205 150 56 6
100
201 171 121 44 20
100
345 219 164 70 20
