58
I
GB
F
PUISSANCE
FRIGORIFIQUE
UNITEES
PAR EAU GLACEE
COOLING CAPACITY
CHILLED
WATER UNITS
RESE FRIGORIFERE
UNITÀ AD ACQUA
REFRIGERATA
J*CC
0020 0025 0030 0040 0060
Fa

444 639 639 931 1250

1600 2300 2300 3350 4500
Pven 0,52 0,64 0,64 1,07 1,26
฀
฀
฀฀
฀฀
TOT 5,8 7,9 8,7 11,5 16,6
SENS 5,8 7,9 8,7 11,5 16,6
FW 992 1355 1497 1964 2842
PDb 11,1 14,9 9,5 15,5 28,4
PDv 6,2 4,6 5,6 9,7 10,9
PDt 17,3 19,5 15,2 25,2 39,4
฀฀
฀฀
TOT 4,3 5,9 6,5 8,5 12,3
SENS 4,3 5,9 6,5 8,5 12,3
FW 738 1006 1115 1450 2116
PDb 6,4 8,6 5,5 8,8 16,4
PDv 3,3 2,5 3,1 5,2 5,9
PDt 9,8 11,1 8,6 14,0 22,4
฀฀
฀฀
TOT 3,3 4,5 5,0 6,4 9,5
SENS 3,3 4,5 5,0 6,4 9,5
FW 562 769 855 1099 1623
PDb 3,9 5,2 3,4 5,3 10,1
PDv 1,9 1,4 1,8 3,0 3,5
PDt 5,8 6,7 5,2 8,3 13,5
฀
฀
฀฀
฀฀
TOT 7,2 9,9 10,9 14,0 20,8
SENS 6,6 9,0 9,9 13,2 18,8
FW 1232 1704 1868 2391 3558
PDb 16,4 22,5 14,2 22,1 42,6
PDv 9,5 7,3 8,8 14,4 17,1
PDt 25,9 29,8 23,0 36,5 59,8
฀฀
฀฀
TOT 5,3 7,2 8,0 10,5 15,2
SENS 5,3 7,2 8,0 10,5 15,2
FW 908 1238 1373 1796 2599
PDb 9,3 12,4 8,0 13,0 23,8
PDv 5,1 3,8 4,7 8,0 9,0
PDt 14,4 16,2 12,7 21,0 32,8
฀฀
฀฀
TOT 4,3 5,9 6,5 8,5 12,3
SENS 4,3 5,9 6,5 8,5 12,3
FW 738 1006 1115 1455 2116
PDb 6,4 8,5 5,4 8,8 16,3
PDv 3,3 2,5 3,0 5,2 5,9
PDt 9,7 10,9 8,5 14,0 22,1
฀
฀
฀฀
฀฀
TOT 9,6 13,3 14,6 18,8 27,9
SENS 7,4 10,2 11,0 14,8 21,2
FW 1652 2279 2497 3220 4773
PDb 27,9 37,9 23,9 37,8 72,3
PDv 17,1 13,1 15,7 26,1 30,8
PDt 44,9 51,0 39,6 63,9 103,1
฀฀
฀฀
TOT 6,3 8,5 9,4 12,4 17,9
SENS 6,3 8,5 9,4 12,4 17,9
FW 1074 1463 1619 2132 3071
PDb 12,6 16,8 10,8 17,7 32,1
PDv 7,1 5,3 6,5 11,2 12,5
PDt 19,7 22,1 17,2 28,9 44,7
฀฀
฀฀
TOT 5,3 7,2 8,0 10,5 15,1
SENS 5,3 7,2 8,0 10,5 15,1
FW 907 1236 1368 1794 2597
PDb 9,2 12,2 7,9 12,8 23,5
PDv 5,0 3,7 4,6 7,9 8,9
PDt 14,2 16,0 12,4 20,7 32,4
Pvent: Potenza nominale dei ventilatori
IWT : Temperatura ingresso acqua
OWT : Temperatura uscita acqua
Fa : Portata d’aria (@20Pa)
Tot : Potenza frigorifera totale
Sens : Potenza frigorifera sensibile
FW : Portata di acqua refrigerata
PDb : Perdita di carico - batteria
PDv : Perdita di carico - totale
฀
Nominal power
Intake water temperature
Outlet water temperature
Air flow (@20Pa)
Total cooling capacity
Sensible cooling capacity
Chilled water flow rate
Pressure drop - coil only
Pressure drop - totale

Puissance nominale ventilateur
Température entrée eau
Température sortie eau
bit d’air (@20Pa)
Puissance frigorique - totale
Puissance frigorique - sensibile
bit d’eau glacée
Perte de charge seulement batterie
Perte de charge - totale
฀
