Table 7. Group 7 lockout (Must have OAT enabled to use either Internet Weather or a sensor wired to ODT input for
Group 7 to appear) (continued)
Menu Item Options [Default] Description
Defrost Heater Balance Point (W1) Setting 40°F to 55°F, [55°F] Select an outdoor temperature to disallow 1st, 2nd
and 3rd stage of indoor heat during defrost above
this temperature
Defrost Heater Balance Point (W2) [Disable], Enable Enable defrost heater balance point for W1 and W2
(only applicable when indoor heat is electric or
hydronic)
Defrost Heater Balance Point (W2) Setting 10°F to 50°F, [40°F] Select an outdoor temperature to disallow 2nd and
3rd stage of indoor heat during defrost above this
temperature
Defrost Heater Balance Point (W3) [Disable], Enable Enable defrost heater balance point for W3 only
(only applicable when indoor heat is electric or
hydronic)
Defrost Heater Balance Point (W3) 5°F to 45°F, [25°F] Select an outdoor temperature to disallow 3rd
stage of indoor heat during defrost above this
temperature
Compressor Cooling 1st Stage Lockout [Disable], Enable Enable compressor cooling 1st stage lockout
Compressor Cooling 1st Stage Lockout Setting 80°F to [120°F] Select an outdoor temperature to force the system
2nd stage compressor cooling
Compressor Heating 1st Stage Lockout [Disable], Enable Enable compressor heating 1st stage compressor
heating lockout
Compressor Heating 1st Stage Lockout Setting 0°F to [50°F] Select an outdoor temperature to force the system
to 2nd stage compressor heating
1st Stage Lockout [Disable], Enable Enable furnace heating 1st stage lockout
1st Stage Lockout Setting 0°F to [50°F] Select an outdoor temperature to force the system
to 2nd stage furnace heating
Service Reminders
Reminders can be enabled to trigger an alert when service is required. The reminder is time-based and
can be configured on system run time or calendar days. Reminders can be configured for humidifiers,
filters, ventilation systems, UV lights, and HVAC system maintenance. The type of reminders available
are based on the accessories enabled in the installer settings.
Contractor Code
When a Pivot thermostat is connected to the internet, a contractor code can be entered to auto-populate
the contractor’s contact information and logo. The code is the contractor’s registered phone number
listed on ComfortSite. The contractor code is also used to associate the thermostat with a specific
contractor on the Contractor Diagnostic Portal. If contractors do not have an account in ComfortSite,
they will need to work with their local Trane office to set up the account. The contractor information
required in the thermostat can be left blank until a contractor account has been set up in ComfortSite. At
the thermostat navigate to Home > Menu > Service > Contractor Code > Next >. Enter the contractor
phone number registered in Comfortsite.
Software Updates
Software updates will occur automatically when the Pivot thermostat is connected to the internet. To
manually force the thermostat to update, navigate to Home > Menu > Reboot. The thermostat will
update within an hour, provided you do not touch the screen.
Note: The thermostat will only update if an update is available.
System Setup
