BAS-SVX078E-EN
31
Modes
System Mode
The Pivot thermostat has five (5) system modes:
• Heating; system only operates in heating mode.
• Cooling; system only operates in cooling mode.
• Off; system does not operate in either heating/cooling modes.
• Emergency Heating; system operates only the indoor heat source.
Note: Only available when the outdoor unit type is a heat pump.
• Auto; the unit determines which mode of operation based on the following rules:
– The indoor temperature is ≤ heating setpoint.
– The indoor temperature is ≥ cooling setpoint or within 1°F of cooling setpoint.
Note: There is a minimum deadband between heating/cooling setpoints of 3°F.
Operation
