PTAC-SVX002A-EN
17
System Configuration
Adjusting Air Direction- Only for Duct Installations
1. Remove front panel.
2. Remove louver screws that hold the louver insert in place on the back side of the front panel.
3. Turn louver insert and rotate it 180°.
4. Replace louver insert.
5. Replace screws and the front panel.
