PTEC-M-1A
Diagnostic
Charts
Cooling Change of Temperature - Air Conditioners
Model
Room Air Room Air PTEC0701 PTEC0702 PTEC0901 PTEC0902 PTEC1201 PTEC1202 PTEC1501 PTEC1502
Dry Wet Temperature Across Temperature Across Temperature Across Temperature Across
Bulb Bulb Indoor Coil ( D T) Indoor Coil ( D T) Indoor Coil ( D T) Indoor Coil ( D T)
°F °F Min Max Min Max Min Max Min Max
85132 61514
80 6 11 10 15 9 13 8 13
90 75 15 19 18 23 17 22 16 21
70 23 28 27 31 25 30 24 29
80 3 8 7 11 5 10 5 9
75 11 16 14 19 13 18 12 17
85 70 18 23 22 26 20 25 20 24
65 26 31 29 34 28 33 27 32
75 7 12 10 15 9 13 8 13
70 14 18 17 21 15 20 15 19
80 65 20 25 23 28 22 26 21 26
60 27 31 30 34 28 33 28 32
7091412 1710151015
65 14 19 17 22 15 20 15 20
75 60 19 24 22 27 20 25 20 25
55 24 29 27 32 25 30 25 30
65 9 13 11 15 9 13 9 14
70 60 13 17 15 19 13 17 13 18
55 17 21 19 23 17 21 17 22
Cooling Change of Temperature - Air Conditioners
Temperature Model
Room Air Room Air PTHC0701 PTHC0702 PTHC0901 PTHC0902 PTHC1201 PTHC1202 PTHC1501 PTHC1502
Dry Wet Temperature Across Temperature Across Temperature Across Temperature Across
Bulb Bulb Indoor Coil ( D T) Indoor Coil ( D T) Indoor Coil ( D T) Indoor Coil ( D T)
°F °F Min Max Min Max Min Max Min Max
85132 61514
80 6 11 10 15 9 13 8 13
90 75 15 19 18 23 17 22 16 21
70 23 28 27 31 25 30 24 29
80 3 8 7 11 5 10 5 9
75 11 16 14 19 13 18 12 17
85 70 18 23 22 26 20 25 20 24
65 26 31 29 34 28 33 27 32
75 7 12 10 15 9 13 8 13
70 14 18 17 21 15 20 15 19
80 65 20 25 23 28 22 26 21 26
60 27 31 30 34 28 33 28 32
7091412 1710151015
65 14 19 17 22 15 20 15 20
75 60 19 24 22 27 20 25 20 25
55 24 29 27 32 25 30 25 30
65 9 13 11 15 9 13 9 14
70 60 13 17 15 19 13 17 13 18
55 17 21 19 23 17 21 17 22
