Trane PTHC-090 - Cooling Amperage Chart - Air Conditioner

PTEC-M-1A
50
Diagnostic
Charts
Cooling Amperage Chart - Air Conditioner
Cond Inlet Air
Temperature PTEC0701 PTEC0702 PTEC0901 PTEC0902 PTEC1201 PTEC1202 PTE1501 PTEC1502
(°F) Amperage Amperage Amperage Amperage Amperage Amperage Amperage Amperage
Min Max Min Max Min Max Min Max Min Max Min Max Min Max Min Max
100 2.8 3.0 2.3 2.5 3.5 3.9 2.7 2.9 4.8 5.4 4.0 4.4 6.4 7.1 5.8 6.4
95 2.6 2.9 2.2 2.4 3.3 3.7 2.5 2.8 4.6 5.1 3.8 4.2 6.0 6.7 5.5 6.1
90 2.5 2.8 2.1 2.3 3.2 3.5 2.4 2.7 4.4 4.9 3.7 4.0 5.7 6.4 5.3 5.8
85 2.4 2.7 2.0 2.2 3.0 3.3 2.3 2.5 4.2 4.6 3.5 3.9 5.4 6.0 5.0 5.5
80 2.3 2.5 1.9 2.1 2.9 3.2 2.2 2.4 4.0 4.4 3.3 3.7 5.1 5.7 4.8 5.3
Cooling Amperage Chart - Air Conditioner
Cond Inlet Air
Temperature PTHC0701 PTHC0702 PTHC0901 PTHC0902 PTHC1201 PTHC1202 PTHC1501 PTHC1502
(°F) Amperage Amperage Amperage Amperage Amperage Amperage Amperage Amperage
Min Max Min Max Min Max Min Max Min Max Min Max Min Max Min Max
100 2.8 3.0 2.4 2.6 3.5 3.9 2.8 3.0 4.8 5.3 4.2 4.6 6.4 7.1 5.7 6.3
95 2.6 2.9 2.3 2.5 3.3 3.7 2.6 2.9 4.5 5.0 4.0 4.4 6.0 6.7 5.4 6.0
90 2.5 2.7 2.1 2.4 3.2 3.5 2.5 2.8 4.3 4.8 3.8 4.2 5.7 6.4 5.2 5.7
85 2.3 2.6 2.0 2.2 3.0 3.3 2.4 2.7 4.1 4.5 3.6 4.0 5.4 6.0 4.9 5.4
80 2.2 2.4 1.9 2.1 2.9 3.2 2.3 2.5 3.9 4.3 3.4 3.8 5.1 5.7 4.7 5.1
