51
PTEC-M-1A
Diagnostic
Charts
Heating Wattage
Temperature Model
PTHC0701 PTHC0702 PTHC0901 PTHC0902 PTHC1201 PTHC1202 PTHC1501 PTHC1502
Outside
Air Room Air Total Wattage Total Wattage Total Wattage Total Wattage
Dry Bulb Dry Bulb Input Input Input Input
F° F° Min Max Min Max Min Max Min Max
85 615 660 810 855 1095 1180 1450 1585
80 595 640 790 835 1075 1155 1425 1555
50 75 580 625 775 820 1050 1135 1395 1530
70 565 610 755 800 1030 1110 1370 1500
65 550 595 735 780 1005 1085 1340 1475
85 595 640 775 820 1060 1140 1390 1520
80 580 625 755 800 1035 1120 1360 1495
45 75 560 605 740 785 1015 1095 1335 1470
70 545 590 720 765 990 1070 1305 1440
65 530 575 700 745 970 1050 1280 1415
85 575 620 740 785 1010 1100 1325 1460
80 560 605 720 765 1000 1080 1300 1435
40 75 545 590 700 745 975 1055 1270 1405
70 525 570 685 730 950 1035 1245 1380
65 510 555 665 710 930 1010 1220 1350
85 555 600 705 750 985 1065 1265 1400
80 540 585 685 730 960 1040 1240 1370
35 75 525 570 665 710 935 1020 1210 1345
70 510 555 650 695 915 995 1185 1315
65 490 535 630 675 890 975 1155 1290
Heating Change of Temperature
Temperature Model
Room Air Room Air PTHC0701 PTHC0702 PTHC0901 PTHC0902 PTHC1201 PTHC1202 PTHC1501 PTHC1502
Dry Wet Temperature Across Temperature Across Temperature Across Temperature Across
Bulb Bulb Indoor Coil (
D
T) Indoor Coil (
D
T) Indoor Coil (
D
T) Indoor Coil (
D
T)
°F °F Min Max Min Max Min Max Min Max
85 21 25 27 32 30 34 29 33
80 22 2 28 33 31 35 30 34
50 75 23 27 29 34 32 36 31 35
70 25 29 31 36 34 38 33 37
65 25 29 31 36 34 38 33 37
80 18 23 24 29 27 32 28 33
80 19 24 25 30 28 33 29 34
45 75 20 25 26 31 29 34 30 35
70 21 26 27 32 30 35 31 36
65 22 27 28 33 31 36 32 37
85 16 21 22 26 25 30 28 33
80 17 22 23 27 26 31 29 34
40 75 18 23 24 28 27 32 30 35
70 19 24 25 29 28 33 31 36
65 20 25 26 30 29 34 32 37
85 14 18 19 24 23 27 28 32
80 15 19 20 25 24 28 29 33
35 75 16 20 21 26 25 29 30 34
70 17 21 22 27 26 30 31 35
65 18 22 23 28 27 31 32 36
