General Information
6 CVRF-SVN005C-EN
Remove the existing chiller nameplate on the unit and relocate
to the outside of the new control panel. Important information
is contained on this existing nameplate that must be retained
for future unit servicing.
If nameplate cannot be removed and relocated, copy
information from old nameplate onto new vinyl nameplate
included in retrofit package.
Symbio™ Panel Conversion Kit
Contents
Each Symbio™ panel conversion kit includes a pre-assembled
control panel with a number of standard features and options
installed, wired, bound, and tested, along with some device
LLIDs shipped loose that require field installation and binding.
Before commencing the Symbio™ control retrofit, be sure to
compare the data on the panel nameplate and ordering and
shipping information to the data in the following tables to verify
that the proper Symbio™ components were shipped. The
tables are split into those components that are factory installed
and those that are shipped loose and need to be field installed.
If an inspection of the conversion package reveals damage or
material shortages, be sure to file these claims with the carrier
immediately. Specify the extent of the damage or material
shortages and be sure to notify the appropriate Trane
representative. Do not install a damaged component or panel.
Table 2. LLID legend and identification
(a)
LLID Name Description Part Number
Tracer® Adaptiview™ color display MOD03183
LON
LonTalk
®
Communications interface for chillers
KIT18458, KIT; ECHELON MODULE FIELD INSTALL
KIT
DAIO Dual analog input and output BRD04875
DBI Dual low voltage binary input BRD04873
DHVBI Dual high voltage binary input BRD04874
DRO Dual relay output BRD04878
HPRO High power relay output MOD01401
IGV Inlet guide vane stepper actuator ACT00680
Power supply 27 Vac to 24 Vdc for bus power supply BRD02102
Pressure sensor Low pressure range, 0 to 50 psia TDR00733
Pressure sensor High pressure range, 0 to 475 psia TDR00734
Pressure transducer
Danfoss pressure transducer, 475 PSI
7/16-20 NUF
TDR00735
QRO Quad relay output BRD04879
Starter module Trane control board, starter module BRD04877
Starter module power supply 110 Vac/24 Vdc power supply PWR00147
Starter module on sub plate without power supply or LV
PTs
Starter sub-panel for unit mount medium voltage
starters
018504210100
Starter module on sub plate without power supply with
LV PTs
Starter sub-panel for remote mount medium voltage
starters
018504330100
Starter module on sub plate with power supply without
LV PTs
Starter sub-panel for unit mount low voltage starters 018504220100
Starter module on sub plate with power supply and LV
PTs
Starter sub-panel for remote mount low voltage
starters
018504350100
AFD starter nodule on sub plate without power supply
or LV PTs
Assembly for unit mount UCP2 AFDB, AFDC, and non-
communicating AFDH
018504340100
AFD starter nodule on sub plate with power supply
without LV PTs
Assembly for remote mount UCP2 AFDB, AFDC, and
non-communicating AFDH
018504370100
Temp sensor Low range temperature sensor SEN02133
Triac Dual triac output BRD04876
TWTI Triple winding temperature input MOD02462
Symbio™ controller MOD02979
