52 CLCH-SVX07C-EN
Component Installation Requirements
Figure 42. 2-inch and 4-inch angled filter placement for unit sizes 57-120
Size 57
20
20 1.5
20
20
20
20
20
2020202020
100.00 ft
²
Size 66
20
16 .5
20
20
20
20
20
202020202020
113.33 ft
²
Size 80
16 .5
20
20
20
20
20
20
20
20
202020202020
151.11 ft
²
Size 100
20
25 25 25 25 25 25 .5
20
20
20
20
20
20
20
166.67 ft
²
Size 120
20
25 3
20
20
20
20
20
20
20
252525252525
194.44 ft
²
