54 CLCH-SVX07C-EN
Component Installation Requirements
Figure 44. Bag and cartridge side-loading filter placement for unit sizes 57-100
Size 57
24
24
24
24
3.524 24 24 24
60.00 ft
²
Size 66
20
24
20
20
20
24 24 24 24 18.5
66.67 ft
²
Size 80
24
24 6.9
24
24
24
24 24 24 24 12
88.00 ft
²
Size 100
12
20
24
1.7
24
24
24
24 24 24 24 24 24 8.9
20 20 20 20 20 20 12
111.33 ft
²
Size 120
24
24 1.2
12
24
24
24
24 24 24 24 24 24 12
12.8
134.00 ft
²
