CLCH-SVX07C-EN 69

Component Installation Requirements

Table 19. Energy recovery recirculation parallel damper

Unit size A (in) B (in) Damper qty Torque (in-lb.)

Actuator torque

(max) (in-lb.) Actuator qty Linkage

3 16.00 13.97 1 10.9 42 1 No

4 28.50 13.97 1 19.4 42 1 No

6 28.50 13.97 1 19.4 42 1 No

8 35.00 13.97 1 23.8 42 1 No

10 46.00 13.97 1 31.2 42 1 No

12 51.00 13.97 1 34.6 42 1 No

14 56.50 13.97 1 38.4 160 1 No

17 56.50 13.97 1 38.4 160 1 No

21 64.50 13.97 1 43.8 160 1 No

25 64.50 13.97 1 43.8 160 1 No

30 78.00 13.97 1 53.0 160 1 No

35 84.50 13.97 1 57.4 160 1 No

40 97.00 13.97 1 65.9 160 1 No

50 110.00 13.97 1 74.7 160 1 No

Table 20. Energy recovery bypass opposed blade damper

Unit size A (in) B (in) Damper qty Torque in-lb.

Actuator Torque

(max) (in-lb.) Actuator qty Linkage

3 - 8 18.00 8.22 1 5.10 42 1 No

8 - 14 32.00 8.22 1 9.10 42 1 No

10 - 17 41.75 8.22 1 11.90 42 1 No

12 - 21 53.50 8.22 1 15.30 42 1 No

21 - 50 52.50 13.97 1 25.50 160 1 No

17, 21 61.50 8.22 1 17.60 42 1 No

21 - 30 66.00 8.22 1 18.80 42 1 No

25 - 50 65.00 13.97 1 31.50 160 1 No

21 70.00 8.22 1 20.00 42 1 No

35 - 50 84.50 13.97 1 41.00 160 1 No

35 - 50 75.00 13.97 1 36.40 160 1 No

40 - 50 102.00 13.97 1 49.50 160 1 No

50 113.00 13.97 1 54.80 160 1 No
