54
TK 55676-19-IM-EN
Figure 29. HMI Harness Connections Shown
RCS1676
4
3
2
1
NNoottee:: Attach the supplied Operator Manual nameplate in a location inside the tractor chosen by the driver.
Figure 30. Online Access to Operator Manual Nameplate Shown
RCS1677
HHMMII IInnssttaallllaattiioonn
