BAS-SVX36C-EN 17
Installation
Figure 14. 3H/2C Non-ProgrammableThermostat, 1H, Conventional With Fan (Option 3)
Rc
R
Y
W2
Y2
L
C
W
G
Fan
L2
L1 (hot)
24 Vac
Heat
(jumper
installed)
Figure 15. 3H/2C Non-ProgrammableThermostat, 1C, Conventional (Option 4)
Rc
R
Y
W2
Y2
L
C
W
G
Fan
L2
L1 (hot)
24 Vac
Compressor
(jumper
installed)
Figure 16. 3H/2C Non-ProgrammableThermostat, 2H/1C, Heat Pump With Auxiliary Heat
(Option 5)
Rc
R
Y
Aux/E
Y2
L
C
O/B
G
Fan
L2
L1 (hot)
24 Vac
Auxiliary Heat
Changeover Valve
Compressor
(jumper
installed)
Zoning Panels
