30 BAS-SVX36C-EN
Configuration
0233 Scheduling mode
day options
0 0 1 day - Mo-Su share the same schedule
1 5+1+1 days - Mo-Fr share a schedule; Sa and Su each have an independent
schedule
2 5+2 days - Mo-Fr share a schedule; Sa-Su share a schedule
3 7 days - Each day has an independent schedule
0240 Heat
temperature
range stops
(6)
90 40 - 90 40° F to 90° F
4 - 32 4° C to 32° C
0241 Cool temperature
range stops
(7)
50 50 - 99 50° F to 99° F
10 - 37 4° C to 32° C
0260 Temperature
display offset
(8)
0 -3 –3° F (–1.5° C)
-2 –2° F (–1.0° C)
-1 –1° F (–0.5° C)
0 None
1 1° F (0.5° C)
2 2° F (1.0° C)
3 3° F (1.5° C)
0270 Extended fan-on
time heat
(9)(10)
0 0 Off
90 90 sec
0271 Extended fan-on
time cool
(9)(7)
0 0 Off
40 40 sec
0300 Restore factory
defaults
0 0 No - do not restore
1 Yes - reset all installer options to default except calendar, and system
selection - options 0120-0122 and 0125-0130 do not reset.
(1) Only available if option #0125 is set to 4.
(2) See “Heat and Cool Cycling Rate,” p. 41.
(3) See “Deadband,” p. 41.
(4) If an external sensor is attached to the S1 and S2 terminals, it must be 10K
negative temperature coefficient.
(5) Only available for heat pump systems with more heat than cool stages and remote outdoor sensor. A 5 °F (2.5 °C) dead
band between options #0220 and #0221 will be enforced automatically.
(6) Only applies to systems with heat stages.
(7) Only applies to systems with cool stages.
(8) Only applies to control temperature and display temperature for internal and indoor remote sensor. Does not apply to out-
door temperature for display.
(9) See “Extended Fan-on Time (Heat or Cool),” p. 42.
(10)Only available when option #0151 is set to 1.
Table 6. Installation Options for 3-Heat/2-Cool ProgrammableThermostat (continued)
No. Name Default Opts. Descriptions
