Configuration
Table 7. Installation Options for 3-Heat/2-Cool Non-ProgrammableThermostat
No. Name Default Opts. Descriptions
01 System type 0 0 1H/1C, conventional - 1st stage heat (W), 1st stage
compressor (Y)
1 1H/1C, heat pump without auxiliary heat - 1st stage compressor (Y),
changeover (O/B)
2 1H, conventional without fan - 1st stage heat (W)
3 1H, conventional with fan - 1st stage heat (W), fan (G)
4 1C, conventional - 1st stage compressor (Y)
5 2H/1C, heat pump with auxiliary heat - 1st stage compressor (Y), changeover
(O/B), auxiliary heat (Aux/E)
6 2H/1C, conventional - 1st & 2nd stage heat (W,W2), 1st stage compressor (Y)
7 1H/2C, conventional - 1st stage heat (W), 1st & 2nd stage compressor (Y, Y2)
8 2H/2C, heat pump without auxiliary heat - 1st & 2nd stage compressor (Y,
Y2), changeover (O/B)
9 3H/2C, heat pump with auxiliary heat - 1st & 2nd stage compressor (Y, Y2),
changeover (O/B), auxiliary heat (Aux/E)
02 Changeover
valve
0 0 O/B terminal energized in cooling
1 O/B terminal energized in heating
03 Fan control
(1)
0 0 Gas or oil furnace, equipment controls fan for heating
1 Electric furnace, thermostat controls fan in heating
04 Stage 1 heat
cycle rate
(2)
5 1-10 Cycles per hour for 1st stage conventional heat - only available on systems
with conventional heat
05 Stage 1
compressor cycle
rate
(2)
3 1-5 Cycles per hour for 1st stage compressor - only available on systems with cool
stages
06 Manual/Auto
changeover
0 0 Manual changeover (heat/cool/off) - manually changeover between heat,
cool, and off
1 Auto changeover (heat/cool/auto/off) - manually changeover between heat,
cool, and off, or select automatic changeover
2 Auto changeover only (auto) - no manual changeover
07 Temperature
indication/
resolution
0 0 °F with 1 degree resolution
1 °F with 0.5 degree resolution
2 °C with 1 degree resolution
3 °C with 0.5 degree resolution
4 °C with 0.1 degree resolution
08 Compressor
protection
5 0-5 Minutes for compressor off time - only available on heat pump systems or
systems with cool stages - (Minutes specified here are added to the 5 min
base off time.)
09 Heat
temperature
range stop
90 40-90 Heating high temperature range stop in °F. (4.5-32°C)
10 Cool temperature
range stop
50 50-99 Cooling low temperature range stop in °F. (10-37°C)
11 Power supply
frequency
0 0 60 Hz
1 50 Hz
12 Deadband
(3)
3 2 2°F (1.0°C)
3 3°F (1.5°C)
4 4°F (2.0°C)
5 5°F (2.5°C)
6 6°F (3.0°C)
7 7°F (3.5°C)
8 8°F (4.0°C)
9 9°F (4.5°C)
13 Stage 2 heat
cycle rate
(2)
9 1-10 Cycles per hour for 2nd stage conventional heat - only available for
conventional systems with at least two stages conventional heat
14 Auxiliary heat
cycle rate
(2)
5 1-10 Cycles per hour for auxiliary heat - only for heat pump systems with more
heat than cool stages
15 Emergency heat
cycle rate
(2)
5 1-10 Cycles per hour for emergency heat - only for heat pump systems with more
heat than cool stages.
16 Stage 2
compressor cycle
rate
(2)
3 1-5 Cycles per hour for 2nd stage compressor - only for systems with two cool
stages
17 Auxiliary heat
control
0 0 Comfort
1 Economy
18 Restore factory
defaults
0 0 No - do not reset
1 Yes - reset all installation configurations (all settings in this table) to default
settings, except System selection
(1) These options only available on systems with fans.
(2)
See “Heat and Cool Cycling Rate,” p. 41.
(3) See “Deadband,” p. 41. For auto or manual systems (see Option 01).
