Trane Thermostats User Manual

32 BAS-SVX36C-EN
Configuration
Table 8. Installation Options for 1-Heat/1-Cool Non-ProgrammableThermostat
No. Name Default Opts. Descriptions
01 System type 0 0 1H/1C, conventional -1st stage heat (W), 1st stage compressor (Y)
1 1H/1C, heat pump - 1st stage compressor (Y), changeover (O/B)
2 1H, conventional, without fan - 1st stage heat (W)
3 1H, conventional with fan -1st stage heat (W), fan (G)
4 1C, conventional - 1st stage compressor (Y)
02 Changeover
valve
0 0 O/B terminal energized in cooling
1 O/B terminal energized in heating
03 Fan control
(1)
(1) These options only available on systems with fans.
0 0 Gas or oil furnace, equipment controls fan for heating
1 Electric furnace, thermostat controls fan in heating
04 Stage 1 heat
cycle rate
(2)
(2) See “Heat and Cool Cycling Rate,” p. 41.
5 1-10 Cycles per hour for 1st stage conventional heat - only available on systems
with conventional heat
05 Stage 1
compressor cycle
rate
(2)
3 1-5 Cycles per hour for 1st stage compressor - only available on systems with cool
stages
06 Manual/Auto
changeover
0 0 Manual changeover (heat/cool/off) - manually changeover between heat,
cool, and off
1 Auto changeover (heat/cool/auto/off) - manually changeover between heat,
cool, and off, or select automatic changeover
2 Auto changeover only (auto) - no manual changeover
07 Temperature
indication/
resolution
0 0 0°F with 1 degree resolution
1 °F with 0.5 degree resolution
2 °C with 1 degree resolution
3 °C with 0.5 degree resolution
4 °C with 0.1 degree resolution
08 Compressor
protection
5 0-5 Minutes for compressor off time - only available on heat pump systems or
systems with cool stages - (Minutes specified here are added to the 5 min base
off time.)
09 Heat
temperature
range stop
90 40-90 Heating high temperature range stop in °F. (4.5-32°C)
10 Cool temperature
range stop
50 50-99 Cooling low temperature range stop in °F. (10-37°C)
11 Power supply
frequency
0 0 60 Hz
1 50 Hz
12 Deadband
(3)
(3) See “Deadband,” p. 41. For auto or manual systems (see Option 01).
3 2 2°F (1.0°C)
3 3°F (1.5°C)
4 4°F (2.0°C)
5 5°F (2.5°C)
6 6°F (3.0°C)
7 7°F (3.5°C)
8 8°F (4.0°C)
9 9°F (4.5°C)
18 Restore factory
defaults
0 0 No - do not reset
1 Yes - reset all installation configurations (all settings in this table) to default
settings, except System selection
