Trane Thermostats User Manual

8 BAS-SVX36C-EN
Introduction
Figure 2. 1-Heat/1-Cool or 3-Heat/2-Cool (non-programmable) Thermostat Dimensions
3.07 in.
(78 mm)
1.1 in.
(28 mm)
4.7 in.
(119 mm)
0.3 in.
(8 mm)
Typ.P Radius 0.08 in. (2 mm)
3.4 in.
(86 mm)
Note: Drawing not to scale. Dimensions within ± 0.02 in. (± 0.5 mm)
Typ. Radius
0.08 in.
(2 mm)

Trane Thermostats Specifications

General

Brand	Trane
Model	Thermostats
Category	Thermostat
Language	English
