Trane Tracer UC400 Installation Guide

14 BAS-SVN026G-EN
Specifications
Sensor Operating
Temperature
32°F to 122°F (0°C to 50°C)
Storage
Temperature
–22°F to 122°F (–30°C to 50°C)
Storage and
Operating
Humidity Range
0% to 95%, non-condensing
Temperature
Control Accuracy
+/- 0.9°F (+/– 0.5°C) @ 70F (21°C) typical calibrated
Temperature
Sensor Resolution
+/– 0.2°F (+/–0.1°C)
Room Air
Temperature
Display Range
–40°F to 122°F (–40°C to 50°C)
Occupied/
Unoccupied
Setpoint Range
• Cooling: 60°F to 85°F (15.5°C to 29.4°C)
• Heating: 55°F to 80°F (12.7°C to 26.6°C)
Heating/Cooling
Setpoint Minimum
Deadband
2°F to 5°F (1.0°C to 2.5°C)
Power Supply 24 Vac (19–30 Vac), 50 Hz or 60 Hz, Class 2
Power Wire
18 AWG or Larger
Power
Consumption
6 VA
Housing
• Polycarbonate/ABS blend
•UV protected
• U.L. 94–5VA flammability rating
• Suitable for application in a plenum
Weight 0.75 lb. (0.34 kg)
Mounting 3.24 in (8.26 cm) for 2 mounting screws (supplied)
Communication
Wire
• 22 AWG or Larger
• Two conductor shielded twisted pair with drain wire
• Characteristic impedance between 100 and 130 ohms
• Capacitance between conductors, less than 100 pF per meter (30 pF
per foot)
• Capacitance between conductors and shield, less than 200 pF meter
(60 pF per foot)
Safety Standards
• LVD Directive 2006/95/EC
• EN60950–a: 2006/A2:2013
• U.L. 873 CSA C22.2 No. 24–93
EMC Standards
• EMC Directive 2004/108/EC
• IEC 61326–1: 2005
• FCC 15 Subpart B, Class A
•ICES-003
RoHS Compliance Enclosure and components are RoHS compliant (RoHS 2002/95/EC)

Trane Tracer UC400 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°F to 158°F (-40°C to 70°C)
Enclosure Rating	IP20
Controller Type	Programmable
Communication Protocol	BACnet MS/TP
Power Supply	24 VAC
Power Consumption	10 VA
Humidity Range	5% to 90% RH non-condensing
Supply Voltage	24 VAC/VDC
